MACHINE DETAILS

1. Fuel Tank
2. Throttle Lever
3. Engine ON/OFF Lever
4. Engine Oil Filler / Dipstick
5. Engine Oil Drain Plug
6. Recoil Starter Handle
7. Choke Lever
Soil, which has been disturbed or new infill, sub base and blacktop, will
have small voids or air pockets which, if not compacted, will lead to one or
more problems occurring.
1. As traffic crosses the surface of an uncompacted area, the material
is compressed. This leads to subsidence of the top surface as the
material fills the voids.
2. A similar situation occurs with static loads on uncompacted ground.
The load (e.g. a building) will sink.
3. Materials with voids are more susceptible to water seepage, leading
to erosion. Water ingress may also cause the soil to expand during
freezing temperatures and contract during dry spells. Expansion and
contraction is a major cause of damage to building foundations and
normally leads to the structure requiring underpinning.
COMPACTION
8. Idle Set Screw
9. Fuel ON/OFF Lever
10.Air Filter
11.Fuel Drain Plug
12.Spark Plug
13. Exhaust
