Follow the instructions below to install a hard drive, connect to the network and power on
the ShareCenter. Open the shipping carton for the ShareCenter Pro and carefully remove
and unwrap its contents. Follow the instructions below to setup the ShareCenter Pro. If
this is the first time using the ShareCenter Pro or if a new hard disk is installed, use the
Easy Search utility located on the Installation CD and follow the instructions for setting up,
configuring and formatting the new drive.
To install ShareCenter Pro on your local network, refer to the steps below:
1. Open the faceplate to access the drive bays.
2. Remove the HDD tray by pressing the green button.
3. Put a 3.5" SATA hard drive into a drive tray and use
screws to fasten the hard drive with the tray. There
are four holes for fastening the screws. Two holes are
circled in red in the image, and the other two holes are
on the other side of the drive tray.
