The ShareCenter Pro 1100 features an OLED that enables the administrator to easily view
information about the ShareCenter Pro. The OLED screen displays the system information,
hard drive volume information and error messages. The OLED has three different screens:
System Information- This screen shows the following information:
ƒ The hostname of the ShareCenter Pro
ƒ The IP address of the ShareCenter Pro
ƒ The hard drive slots information
Hard Drive Volume information- This screen shows the following information:
ƒ The percentage of space used on the hard drives.
Error Messages- This screen shows error messages when there is any system failure.
Press the button once to alternate between the different Status screens.
D-Link DNS-1100-04 Quick Installation Guide
Using the OLED
3
