Overview
1 Pushing handle, adjustable
2 Cable clamp
3 Cable holder, rotating
4 Storage compartment
5 Lock of pushing handle
6 Lid of filter chamber
7 Suction hose connection (for optional
suction set)
8 Fuse for brush drive
9 Fuse for suction turbine
10 Display 'Filter bag is full'
11 Power switch
A Appliance switch in OFF position
B Appliance switch in ON position
Inserting a filter bag
Open lid of filter chamber.
Slide the filter bag into the basket with
the opening facing the connecting hub.
Push the opening of the filter bag over
the connection nozzle.
Close the lid of filter chamber.
Operations
Storing and removing the cable
Wrap the mains cable of the appliance
around the three cable holders.
Remove the entire mains cable by turn-
ing the rotating cable holder.
Adjust the pushing handle
Swivel the pushing handle lock to the
outside, set the desired pushing handle
height and close the lock.
