FRONT PANEL
1
ON / OFF SWITCH
1
INDICATOR LEDS 1-16 FOR WIN42 RECEIVERS 1-16
2
REAR PANEL
4
AC ADAPTER CONNECTOR (9 - 18 V DC, 300 MA)
1
DATA PORT FOR USB TO RS485 CONVERTER
2
DATA CONNECTORS (COM 1 - 16) FOR WIN42 RECEIVERS
3
PROVISION FOR PORT ExPANSION (CURRENTLy UNAVAILABLE)
4

FRONT / REAR PANEL:

2
3 2 1
7
