Promise Technology SUPERTRAK EX16300 Kurzanleitung Seite 7

Ch1-4
LED Pins
Ch1-4
LED Pins
2. Attach one SATA fanout cable to each four-channel connector on the
SuperTrak card (above). Then attach the other ends of the fanout cable to
the data connectors on the disk drives.
Ch9-12
Ch13-16
Ch5-8
Ch9-12
Ch13-16
Ch5-8
EX16350
SuperTrak
7
Step 3: Install the Disk Drives
SuperTrak EX16300
EX16300
SuperTrak
SMBus connector for
SAF-TE enclosure
SuperTrak EX16350
SMBus connector for
SAF-TE enclosure
BBU module
connector
BBU module
connector
