The Pool Basic Pro EVO control method belongs to a new line of instruments carefully
developed by the supplier for the innovative management of pools. This device is easy to use
and permits continuous control of the pH.
The peristaltic pumps have a 1,5 l/h flow rate for pH regulation and have a pressurised
injection flow rate up to 1.5 bar.
This easy-to-use instrument does not require special maintenance operations. It is equipped
with a self-regulation procedure and automatic control of the electrode's state.
Disconnect power before carrying out ANY operation inside the control
panel of the Pool Basic Pro EVO device.
NON-OBSERVANCE OF THE INSTRUCTIONS CONTAINED IN THE PRESENT MANUAL
COULD CAUSE INJURY TO PEOPLE AND/OR DAMAGE TO THE DEVICE.
During installation of the Pool Basic Pro EVO device, proceed as follows:

Make sure that the supply voltage coincides with the one indicated on the label on the side
of the device.

Make sure that the injection pressure is below 1.5 bar.

Make sure that the pump's protective cover is properly latched.

Make sure that the suction hose is immersed with the relative foot (PVC hose) in the tank
of the product which must be injected and that it is connected to the pump (symbol on
cover ▲). After carrying out the checks stated above, tighten the connector nut.

Connect one end of the delivery hose (▼ symbol on cover) to the pump and connect the
other end to the pool through the injection valve.
NOTE: To insert the product which must be injected into the pump when starting for the first
time and every time the tank is changed, set the switch to forced running using the
button.
000013791

1. GENERAL INTRODUCTION

2. INSTALLATION PRECAUTIONS

WARNING!!!
WARNING
Rev. 1.0
3
