CONTROLS AND FUNCTIONS
1. AUDIO OUTPUTS – The music-signal of these sockets is analogue. Connect the output to the
respective input of your mixer.
2. RELAY SOCKET – Via the RELAY SOCKET, two USB players can relay play. If you connect with a
mixer which supporting fader start, you can also relay play via mixer's cross-fader.
3. POWER SWITCH － Press this button to switch the power on/off.
4. AC CONNECTION － Plug the power supply cable in here.
CONTROLS AND FUNCTIONS
16
15
14
1. CUE INDICATOR – This indicator will glow when the device is in CUE mode and will flash every time a
new CUE POINT is set.
2. FOLDER INDICATOR – Indicates the number of the currently playing folder.
3. TIME BAR INDICATOR – Shows either time remaining or elapsed depending on the setting of the TIME
BUTTON. This bar will begin to flash shortly before the end of a track. The flashing bar is a great
visual reminder a track is about to end regardless of which time mode the unit is.
4. BPM STATUS – This will indicate that the AUTO BPM counter is active.
5. BPM METER – Indicates the BPM value of the currently playing track.
6. PITCH METER – Indicates the percentage of a track's pitch.
7. LOOP INDICATOR – Indicates if LOOP function is activated.
8. RELOOP INDICATOR – Indicates if a loop has been set which can be activated with the Reloop function.
9. AUTO CUE STATUS – Indicates if Auto Cue is activated.
10. TIME DISPLAY – Indicates the time of the chosen Time mode in minutes, seconds and frames.
11. ALPHANUMERIC DISPLAY– Indicates the current name of the track, of the folder and the
sampling rate. For VBR recorded MP3 tracks the display only show "VBR". All kinds of other
interactive information are also shown.
12. TIME MODE – Indicates the elapsed time of a track ("ELAPSED") or the remaining time of a track
("REMAIN").
13. REPEAT INDICATOR – Indicates whether the unit is in REPEATED play mode.
14. SINGLE INDICATOR – Indicates whether the play mode is set to single ("SINGLE") or continuous
mode (no display).
15. TRACK INDICATOR – Indicates the number of the currently playing track.
16. PLAY/PAUSE INDICATOR – Indicates the device is in play mode ("
mode (" ").
1
2
1 2 3
12
13 11
5

REAR PANEL

3 4
LCD DISPLAY
4
10 9
"), or the player is in pause
5
6
7
8
