Assembly and operating instructions Type 7E.46
65 A-active-energy meter, three-phase, Fig. 1
Description
The 7E.46 is a compact electronic active power energy
meter for application in 3-phase power lines with
neutral conductor. Depending on the type, the well
readable LCD display offers the reading of additional
values like instantaneous power, total or per phase, as
well as voltages and currents per phase.
Technical data
Connection Fig. 2
■
diagram
Dimensions Fig. 3
■
Accuracy class B, according to EN 50 470-3,
■
Cl. 1 according to IEC 62 053-21
Reference, Maxi- I = 10 A, Im
ref
■
mum, initial current
operating voltage 3 × 230/400 V
■
Tolerance -20%/+15%
Counting range 00000,00...999999,9 kWh
■
S0 output Optocoupler 5 - 30 V
■
(Interface) Impedance 100 Ω,
pulse duration 30 ms
1000 Imp./kWh.
Transmission- Maximum 1000 m (at 30 V/20 mA)
■
distance
Connections Conductor cross-section 1,5 - 16 mm
■
Main circuit Screwdriver Pozi No. 1, slotted
No. 2, breakaway torque 1,5 - 2 Nm
Connections Conductor cross-section max. 2,5 mm
■
Control circuit Screwdriver Pozi No. 0, slotted
No. 2, breakaway torque 0,8 Nm
Operating -10 ... +55°C (noncondensing
■
temperature according standard EN 50 470)
Indicating elements
(Fig. 4)
Shows total consumption Tariff 1
T1total
■
Shows partial consumption for
T1part.
■
Tariff 1, this value is resettable
Shows total consumption Tariff 2
T2total
■
Shows partial consumption for
T2part.
■
Tariff 2, this value is resettable
Shows the instantaneous power
P(kW)
■
per phase or all phases
Shows the voltage per phase
U(V)
■
Shows the current per phase
I(A)
■
Pulsates according to drawn
100 Imp/kWh
■
power
Shows the unit kWh when the
kWh
■
consumption is displayed
For P-, U-, I- or Error display, the
L1 / L2 / L3
■
corresponding phase is displayed
In case of missing phase or wrong
Error
■
current direction. The corresponding
phase is additionally displayed.
4 319 5085 0a
= 65 A, Ist 40 mA
ax =
, 50 Hz
AC
/20 mA,
DC
01.2010
Notes before connecting
1. Do not connect L1, L2 to L3 to N.
2. In order to avoid moisture in the meter due to
condensate build-up, acclimatise the meter at room
temperature for about half an hour before connecting.
Attention!
These devices must only be installed by a professional
electrician, otherwise there is the risk of fire or the risk
of an electric shock.
Operation of the LCD display
The operating menu is shown as a graph on the
figure 4.
Installation instructions
The single-phase energy meter can be attached to a
35 mm rail (EN 60715TH35).
The meter can be used only in installation cabinets.
Declaration of Conformity CE
Finder SpA declares at its own responsibility:
,
2 The following energy meters are in compliance:
7E.46.8.400.0002
■
7E.46.8.400.0012
,
2
■
The following energy meters are approved for energy
billing:
7E.46.8.400.0012
■
which this certificate refer to, are in accordance with
the following standards:
EN 50470 parts 1 and 3 (electronic meter), of
■
October 2006.
Directive 2004/22/EG of the European
■
parliament and of the council regarding measuring
instruments
• Annex I, essential requirements
• Annex MI-003, active electrical energy meters
EC - Declaration of Conformity: 2009
Finder SPA
Conformity Assessment Body:
Zertifizierungstelle METAS-Cert, Nr. 1259
CH-3003 Bern-Wabern
Signed: Marcello Grande, Technical Manager
English
Subject to change without notice
