Operating instructions
Mini WLAN Router N300 with 2 LAN Ports
Item no. 67 63 29
Intended use
The product can be used to connect one or more devices to an existing network or the Internet.
The power supply occurs for this purpose through the mains socket into which the product is
plugged.
Always observe the safety instructions and all other information included in these operating
instructions.
This product complies with the applicable national and European requirements. All names of com-
panies and products are the trademarks of the respective owners. All rights reserved.
Contents
• WLAN router
• Network cable
• Operating instructions
Features
• Power supply through the mains socket into which the device is plugged
• 2 RJ45 network connectors 10/100 Mbit
• WLAN according to 802.11b/g/n (max. 300 MBit)
• WPS via button
Safety Instructions
Please read all the instructions before using this device; they contain important infor-
mation on its correct operation.
The warranty will be void in the event of damage caused by failure to observe these
safety instructions! We do not assume any liability for any resulting damage!
We shall not accept liability for damage to property or personal injury caused by
incorrect handling or non-compliance with the safety instructions! In such cases, the
warranty will be null and void.
• The unauthorised conversion and/or modifi cation of the product is not permitted for
safety and approval reasons (CE).
• The product is intended for use only in dry, indoor locations. No part of the product
should become damp or wet; never handle it if your hands are wet.
There is a life-threatening hazard through an electric shock!
• The design of the product complies with the safety class II. Only a standard mains
socket connected to the public supply may be used as the power source for the
device.
• Protect the product from direct sunlight, strong heat (>35°C), cold (<0°C), dust and
dirt, splashes and dripping water, vibrations or mechanical loads.
• When the product is taken from a cold room to a warm room (e.g., during transport),
condensation may be produced. This could damage the product.
Wait until the product has reached room temperature before using it. This may take
several hours.
• Do not leave packaging material carelessly lying around, since it could become a
dangerous plaything for children.
• Handle the product with care. The product can be damaged if crushed, struck or
dropped, even from a low height.
• If you have any questions that are not answered in these operating instructions,
please contact our technical support centre or consult a professional.
LEDs and buttons on the device
LAN LED lights when network connection at LAN port is active; fl ashes fast during data
transfer
WAN LED lights when network connection at WAN port is active; fl ashes fast during data
transfer
WPS LED fl ashes slowly when WPS is active
WLAN LED lights when WLAN reception is switched on; fl ashes fast during data transfer
POWER LED lights if the router is powered
WPS button press and hold approx. 3 seconds to activate WPS
RESET button press and hold approx. 10 seconds to reset the device to the factory settings
Getting started
• To start using the WLAN router, proceed as follows.
• First, plug the device into a mains socket and wait approx. 1 minute until the device has started
up.
• Confi guration is possible via LAN and WLAN. We recommend carrying out the initial confi gura-
tion through a cable connection. To do this, connect the "LAN" port of the router, using a 1:1
connected network cable, to a free LAN port of your computer.
• Switch on your PC and wait until the operating system has booted up completely.
If you would rather carry out the initial confi guration via WLAN, connect your computer
to the WLAN SSID "Conrad WLAN". Because the WLAN is not encrypted, you do not
need to enter a password here.
However, note that after the confi guration, your PC must be connected to the changed WLAN.
Access to the web interface
• Open your web browser. Enter the IP address http://192.168.10.253/ in the address list and con-
fi rm with Enter.
• A screen will appear in which you have to enter the user name "admin" and "password" for the
password (both without quotes). Then click on OK.
Basic confi guration
Before you begin with the actual confi guration, we recommend that you fi rst change the access
password to the web interface.
• To do this, click on the menu point "Management" in the web interface and then on the subpoint
"Management".
• In the fi eld after "Router Username", enter "admin".
• Enter the password you choose in each of the two fi elds "New Password" and "Re-enter to
confi rm".
• Click "Apply Settings" to confi rm.
Now the actual confi guration of the device occurs. To do this, proceed as follows.
• The simplest way to carry out further confi guration is with the help of the setup program, which
is integrated into the web interface. Therefore, click now in the left-hand menu on the point
"Wizard".
• You now have to select the desired operation mode. We explain the 5 options below.
The AP mode is intended to create a new WLAN access point in your existing network. The
connection to your network must be created here via a network cable. The devices can be con-
nected via WLAN or through the second network connection. The IP addresses are distributed
from your existing router.
Use the "Router" mode when you want to connect the device via network cable directly to a DSL
or cable modem. Devices can access the Internet here via WLAN and via the second network
connection. An independent DHCP server runs on the router.
As "Repeater", the device amplifi es your existing WLAN. It is thus connected to your network
via WLAN. The SSID (WLAN name) is retained. Devices can be operated here at LAN and via
WLAN. The IP addresses are assigned by your existing router.
The "Bridge" mode is in principle a network switch with WLAN. The connection to your network
is created via WLAN. Devices can also be connected via WLAN and via LAN. After the confi gu-
ration, it is also possible to create the connection to your network via cable. The IP addresses
are again distributed by your router.
In "Client" mode, the product acts as a WLAN adapter. It is thereby wirelessly connected to
your existing WLAN. Devices can be operated only at the two RJ45 ports. Here, too, the IP ad-
dresses are assigned by your router.
• When you have decided on an operating mode, select it by clicking on the radio button. Click
"Next" to confi rm.
The individual steps for the respective mode are described below. Thus, carry out only
the confi guration of the mode you selected.
"AP" mode
• First, enter the name of the new WLAN network that the access point is to provide in the fi eld
"SSID".
• Now you still need to defi ne the encryption and the password for the WLAN. Your best bet is
to select "WPA2 Personal" in the menu after "Security Mode" and enter the desired password
after "Key".
• To save the settings and restart, click "Save&Reboot".
• To create the connection to your network, connect the WAN or LAN port of the AP with a free
LAN port of your router or network switch. Use a 1:1 connected network cable for this purpose.
