2. Network connection:
The LAN connection
ly, the existing router (e.g. FRITZ!Box) will automatically assign an IP address.
On the Web interface, "Automatic" (default) will be set under "IP settings".
3. "DC" connection:
Finally, the power supply is to be connected to the server first and then to the network volt-
age.
Overview LED
Tab 1
"Power" LED
"Stream" LED
RF connections
Tab 2
RF1 (950-2,150 MHz)
RF2 (950-2,150 MHz)
RF3 (950-2,150 MHz)
RF4 (950-2,150 MHz)

Additional connections

Ethernet
DC socket Connection of power supply unit
Switch and button
Reset
On/Off
must be
LED ...
Lit green
Off
Lit blue
Flashes blue
Off
Single-cable (EN 50494)
14/18 V; 0/22 kHz
Use
Connection to the network
If switch/button is ...
held down for about
5 seconds
pressed
connected to the
Status EXIP 414
No voltage supply
Network connection generated
Active streaming (data transfer)
Network not connected
Quatro
14 V; 0 kHz
14 V; 22 kHz
18 V; 0 kHz
18 V; 22 kHz
Device is cut off from voltage
5 / 9
home network.
Operation
Quad/DiSEqC™
14/18 V; 0/22 kHz
14/18 V; 0/22 kHz
14/18 V; 0/22 kHz
14/18 V; 0/22 kHz
Specification
10/100/1,000 MBit
12 V/3 A
the following occurs ...
Reset to factory
setting
supply
Normal-
