6mm wooden
dowel
Do the same way with
second wing half.
12
1- Push the 18mm (dia.) Aluminum tube
throughout the fuselage.
2- Carefully, push the right wing to the fuselage,
ensuring that they are accurately aligned.
3- Secure the right wing in place using the
5x20mm screw.
Do the same way with the left wing.
5X25mm screw
5mm washer
....2
13
The holes are Pre-cut
at factory
Thin CA
6mm wooden dowel
......2
TOP VIEW / Draufsicht
TOP VIEW / Draufsicht
CA
Thin CA
CA
Thin CA
8mm
Wing
Wooden dowel
Do the same way with
another half wing.
