2
4x15mm screw
............4
4x40mm screw
......2
4mm Washer
.......................4
4mm Nut
......................4
A-Locate the aluminum landing gear in
the bottom of the fuselage.
B-Drill the hole on each side of the plastic wheel pant.
C-Slide one wheel onto each of the wheel pant and secure
them with the 4x40mm screw and nut.
3
Plastic tail gear mount
......1
3x10mm screw
......2
2mm collar
......1
4
Full the magnetic cockpit out
of the fuselage first.
Full here
3x20mm screw
4x30mm screw
..........4
3mm nut
4mm Blind-nut
................4
3mm washer
................4
4mm washer
C
All holes pre-drilled
at factory
BOTTOM - VIEW / Unteransicht
Collar
1/8(3mm) screw
5mm
4mm
......4
..............4
................4
C
A
CA
5/64
2mm
1/16
1.5mm
!
E
E = 110 - 113mm
5/32"
4mm
4mm nut
4x40mm screw
Aluminum landing
gear
FUSELAGE
Align the mark on both
mounts with the center
mark on the fire-wall
A
A'
FRONT VIEW
Align the engine center with
B
fire-wall marked line (A=A')
B
5/32"
4mm
C
Finish
B
