5
4mm
6
5x70mm screw
...4
5mm Washer
..................16
5mm Nut
.................12
Firewall
SIDE-VIEW
B
B=B'
B'
! Engine thrust on balk head
is already adjust at factory
7
Checking for leaks - block the vents and blow into the
feed - if in doubt submersing the tank in a blow of
water will show up any problems.
5mm
CA
E
E = 110 - 113mm
BOTTOM - VIEW / Unteransicht
2
1
3mm
A=A'
To muffler
Filler tube
Rubber
stopper
Stopper
To engine
Cap
Water
Using a aluminum motor mounting plate as
a template, mark the plywood motor mounting
plate where the four holes are to be drilled (2).
Remove the aluminum motor mounting
plate and drill a 1/8"(3mm) hole through
the plywood at each of the four marks
marked .
Note: The aluminum motor mounting included
with electric motor set.
TOP-VIEW
A
A'
! Engine thrust on balk head
is already adjust at factory
X
Blow
