RECOMMENDED ACCESSORIES (Purchase separately)
Empfohlenes Zubehör (Nicht im Lieferumfang enthalten)
4 - channel radio
4 - Kanal
Fernsteuerung
Cyanoacrylate Glue
Sekundenkleber
Tool Required/ Empfohlenes Werkzeug
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
The pre-covered film on ARF kit may wrinkle due to variations of temperature.
Store model in a cool and dry place for awile.
Then, staring with low heat, you may carefully use a hair dryer to smooth out wrinkels.
Die Bespannung des Modells kann durch Temeratureinflusse erschlaffen oder Falten
werfen z.b bei zu starker Sonnenenstrahlung oder Hitze.
Stellen Sie das Modell zunachst an einen kuhlen Platz fur eine bestimmte Zeit. Danach
konnen Sie versuchen die restlichen Falten vorstichtig mit einem Haartrockner zu behandeln.
Drill holes using the stated
size of drill
1.5mm
(in this case 1.5 mm Ø)
A B
Use epoxy glue
CONVERSION TABLE
3.0mm = 1/8"
1.0mm = 3/64"
4.0mm = 5/32"
1.5mm = 1/16"
5.0mm = 13/64"
2.0mm = 5/64"
6.0mm = 15/64"
2.5mm = 3/32"
Antrieb Standard:
BOOST 40 Brushless Combo Set, Best.Nr. C2983
LiPo Battery RED POWER 3200-3S, Best.Nr. C3164
Luftschraube 12*6, Best.Nr. C1937
Antrieb Tuning (Kraftvoller Kunstflug):
BOOST 60 Brushless Combo Set, Best.Nr. C3174
LiPO Akku RED POWER 4250-5S, Best.Nr. C4547
Luftschraube 13*8, Best.Nr. C2846
SILICON
CA
!
Take particular care here
Apply cyano glue
CA
10mm = 13/32"
12mm = 15/32"
15mm = 19/32"
20mm = 51/64"
Silicon Glue
Silikonkleber
Hatched-in areas:
remove covering
film carefully
Assemble left and right
L/R
sides the same way.
25mm = 1"
30mm = 1-3/16"
45mm = 1-51/64"
Egänzungskit Verbrenner
(Tank + Motorträger)
Best.Nr. C4165
1 x Servo S4020
(für Seitenruder)
Best.Nr. C1687
3 x Servo S4020
(für Höhen- und Querruder)
Best.Nr. C4995
EPOXY A
EPOXY B
Epoxy Glue (30 minutes type)
Epoxy-Klebstoff (30min)
!
Check during assembly that these
parts move freely, without binding
Not included.
X
These parts must be
purchased separately
