Description of the oven

1
2
3
4
5
6
7
8

Control panel

B6335.0 / B6330.0
Models
H6120.0 Models
22
User's Guide
3
5 4 3
1 Temperature control dial.
2 Electric clock/timer.
3 Function control dial.
9
10
11
12
13
14
15
2
2 1
1 Control panel
2 Door lock (only for
pyrolytic models)
Grill element
3
4 Tray supports
5 Grid shelf
6 Tray
7 Hinge
8 Inner Glass
Air cooling outlet
9
Unit mounting
10
Lamp
11
12 Back Wall Panel
13 Fan
14 Oven Seal
15 Door
1
4 Pilot light cooking zone.
5 Cooking zone controls.
