Electric installation

The panel is fitted with a two- conductor cable for 1/N 230 V / Hz.
Colour marking of the conductors:
Phase – brown
Central (live) conductor – blue
The power supply cable is connected to a box on the wall, see Fig 3.
The panel must not be placed directly under an electric socket.
The supply cable must be fitted with a device for disconnection from the mains in which the distance between the disconnected
contacts is at least 3.5 m for all poles.
If the supply cable of this appliance is damaged, it has to be replaced by the producer or a service technician.
Controlling the panel
We recommend controlling this panel using an external room thermostat with a switch (e.g. Fenix Therm 100).
The room thermostat maintains the set air temperature in the room.
Furthermore, the panel is fitted with a limit thermostat which ensures its safe operation.
Uninstalling the panel
Disconnect the panel from the mains using a two- pole switch before uninstalling it. Lift the panel upwards vertically and side-
ways in such a way that it is released from the screws. Furthermore, the supply cable must be disconnected from the box on
the wall.
Caution
Only qualified persons may carry out work on the panel. Before launching such work, the panel must be disconnected from the
source of power. As it is made of fragile material, great care needs to be taken during transport, manipulation and installation.
This appliance is not intended for use by persons (including children) whose lack of physical, sensory or mental ability or lack
of experience and knowledge prevents them from safely using the appliance, unless they are supervised or have received in-
structions regarding the use of the appliance from a person who is responsible for their safety. Children should be supervised in
order to prevent them from playing with the appliance.
Important safety instructions – WARNING
Do not cover the panel in any situation. The notice "NEZAKRÝVAT" ("DO NOT COVER") notifies that any material covering the
panel may cause a fire. Furniture must not be placed and curtains must not be hung in front of the panel (see Fig. 6) and
free circulation of air must be ensured. Dust must be removed from the panel regularly, at least before the beginning of every
heating season. Do not touch the panel when in the bathtub or shower!
WARNING: The heater must not be used if the glass is damaged.
The panel can be installed on bases of flammability class
C or D.
