Electric installation

The panel is fitted with a two- conductor cable for 1/N 230 V / 50 Hz with a plug for connection into a socket
Removal of the plug and shortening of the supply lead will not result in loss of warranty
Colour marking of the conductors:
Phase – brown
Central (live) conductor – blue
The power supply cable is connected to a box on the wall, see Fig 3.
The panel must not be placed directly under an electric socket.
The supply cable must be fitted with a device for disconnection from the mains in which the distance between the disconnected contacts is
at least 3.5 m for all poles. If the supply cable of this appliance is damaged, it has to be replaced by the producer or a service technician.
Controlling the panel
We recommend controlling this panel using an external room thermostat with a switch.
The room thermostat maintains the set air temperature in the room.
Furthermore, the panel is fitted with a limit thermostat which ensures its safe operation.
Uninstalling the panel
Disconnect the panel from the mains using a two-pole switch before uninstalling it. Lift the panel upwards vertically and sideways in such a
way that it is released from the screws. Furthermore, the supply cable must be disconnected from the box on the wall.
Caution
Only qualified persons may carry out work on the panel. Before launching such work, the panel must be disconnected from the source of
power. As it is made of fragile material, great care needs to be taken during transport, manipulation and installation.
This appliance can be used by children from the age of 8 and older, and persons with lower physical, sensory or mental abilities or a lack of
experience or knowledge providing they are under supervision or have been trained in the use of the appliance in a safe manner and under-
stand the possible danger. Children may not play with the appliance. Cleaning and maintenance by the user must not be carried out by
children
without supervision.
Children under 3 years of age should be prevented from accessing the appliance, unless they are constantly supervised. Children from 3 to 8
years of age may switch the appliance on/off only if it is placed or installed in its intended standard operating position and if they are under
supervision or have been instructed in the safe use of the appliance and if they understand the possible danger. Children from 3 to 8 years of
age mustn´t insert the plug into the socket, control or clean the appliance or carry out maintenance that is to be done by the user.
WARNING – Some parts of this product may become very hot and cause burns. Special attention must be paid to this fact in the presence
of children and handicapped persons.
Important safety instructions – WARNING
Do not cover the panel in any situation. The notice "NEZAKRÝVAT" ("DO NOT COVER") notifies that any material covering the panel may
cause a fire. Furniture must not be placed and curtains must not be hung in front
of the panel (see Fig. 5) and free circulation of air must be ensured. Dust must
be removed from the panel regularly, at least before the beginning of every
heating season. Do not touch the panel when in the bathtub or shower!
The panel can be installed on bases of flammability class
C or D.
6
.
.
Fig.5
