5 5 S S p p e e c c i i f f i i c c a a t t i i o o n n s s
E E M M C C
EN 61000-4-2 (ESD) 6kV/8kV
EN 61000-4-3 (radiated immunity)
ENV 50204 @AM 10V/average 80MHz - 2,7GHz
EN 61000-4-4 (burst) ~ 2kV; 2kV; I/O 4kV
EN 61000-4-5 (surge) 2/1kV
EN 61000-4-6 (conducted immunity)
ENV 50204 @10V 150kHz - 80MHz
EN 61000-4-29 (voltage variation)
EN 55022 (HF E)
conducted emissions 150kHz - 30MHz
radiated emissions 30MHz - 1GHz pp/average
radiated emissions 30MHz - 1GHz pp/qp
S S h h o o c c k k - - u u n n d d v v i i b b r r a a t t i i o o n n - - t t e e s s t t
IEC 60068-2-6 sinusoidal vibrations
frequencies: 10-57 Hz, amplitude: 0.3 mm
frequencies: 57-500 Hz, acceleration: 2g
IEC 60068-2-27 Shock test, half-sinusoidal
shock acceleration: 15g (operating) 30g (non operating)
shock period: 11ms
E E n n v v i i r r o o n n m m e e n n t t - - t t e e s s t t
IEC 60068-2-1 & IEC 60068-2-2
operating -25°C ... 70°C
non operating -40°C ... 85°C
IEC 60068-2-14 thermal shock
operating 0°C ... 60°C
non operating -40°C ... 80°C
IEC 60068-2-30 damp heat
C C e e r r t t i i f f i i c c a a t t i i o o n n s s
C C l l a a s s s s I I D D i i v v i i s s i i o o n n 2 2
UL Listed Industrial Control Equipment, certified1 for US and
Canada.
CE marking within the EU
GOST R-certification (IEC standards with Russian deviations)
This equipment is suitable for use in Class I Division 2, Groups A,
B, C, and D or Non-Hazardous locations only.
22
