Warning!
Fitting position
Aperture size
Roof Thickness
Fitting direction
Fixing screws
Sealing
Fitting

Fitting Instructions

Never stand on the dome of the rooflight!
(See picture 1)
Choose a fitting position that will not interfere with other roof
mounted components (e.g. roof-racks/antenna's etc.) and avoid
internally installed electrical cables and furniture, which could
impede the correct operation of the rooflight.
The rooflight should only be fitted to a flat roof surface, both in-
ternally and externally.
280x280 mm (see technical data page 5)
Ensure the correct rooflight is selected for the roof thickness. (For
available size options see page 6.)
Rooflights must only be fitted with the operating handles facing
the front and rear of the vehicle, not across the vehicle.
Secure only with pan, or round headed screws (not supplied), 3,5
mm/ head according to DIN ISO 7049 (DIN7981).
Screw size: When fully tightened the screw should enter the outer
frame about 10 mm.
Do not use countersunk screws as they will damage the rooflight
frame.
(See picture 2)
Use only long term flexible sealant, suitable for external use, (not
supplied), and also suitable for the material of the upper frame.
Consult your sealant supplier.
Before fitting the rooflight, remove the flynet, (with optional roller
blind if fitted). The flynet is clipped into place, and is removed by
first opening fully and pulling away from the frame. Reverse the
process to install. Attention: to avoid damage, do not bend the
flynet frame.
Correctly align the upper and lower frames and secure evenly with
the screws. Do not over-tighten as this may damage the frame,
or affect the correct operation of the rooflight. If the inner frame
starts to distort, the correct torque has been reached.
Screws not supplied.
