Instruction for use
Free-air-flow
Before driving
Cleaning
Operation Instruction
The rooflight can be opened fully, or in four different directions, so
that the dome can be angled against driving weather conditions.
To open squeeze the locks (optional) into the handles and push
open.To open the flynet, pull down on the handle. Do not open
more than 90°, to avoid damaging the hinges. When closing the
flynet click back into place. The roller blind (optional) can only be
operated with the flynet in the open position.
When closed there is a free airflow through the rooflight, which
must be kept free at all times. (See technical data page 6.)
IMPORTANT: All rooflights must be closed and locked down before
travelling. (See picture 3-4)

Care Instructions

The rooflight should only be washed by hand, using a sponge with
plenty of clean water to avoid scratching. Caustic detergents and
solvents may attack the plastic and make it brittle or disintegrate.
For easier cleaning of the dome it can be removed from the frame
by releasing the four screws holding the handle arms (Models from
March 2008, Torx TK9 screws. Earlier models had cross recess
screws). (See picture 5)
Make sure that only the original screws are used when replacing
the dome and that they enter the thread in the plastic correctly.
Do not overtighten.
Never remove the screws holding the dome and the handles tog-
ether. (See picture 6)
and should only be handled by an approved dealers.
Remove the flynet, (with optional roller blind if fitted). The flynet is
clipped into place, and is removed by first opening fully and pulling
away from the frame. Reverse the process to install. Attention:
to avoid damage, do not bend the flynet frame. Clean the flynet
mesh and the roller fabric (if fitted) the same way as the dome,
making sure that the metal components of the blind remain dry.
4
These are secured by a torque screwdriver
