Inserting The Batteries In The Remote Control - Carrera RC 370503019 Montage- Und Betriebsanleitung

Note: when supplied, the lipo-battery is al-
ready partially charged. So the first charging
cycle may well take less time.
It is essential to follow the connection se-
quence given above!
Undo the plugged connection on the Quad-
rocopter when you are not using the Quadro-
copter. Failure to observe this precaution may
cause battery damage!
4b
Insertion of the rechargeable batteries
into the Quadrocopter
• Open the cover of the battery compartment
with the aid of the enclosed screwdriver. Insert
the battery. Close the battery compartment.
• If the LED on the Quadrocopter flashes slowly,
you must change the battery.
Inserting the batteries in the
remote control
5
Open the battery compartment with a screw-
driver and insert the batteries in the remote
control. Please keep in mind the correct polar-
ity. Different types of batteries or new and
used batteries are not to be mixed. After hav-
ing closed the compartment you can check all
functions of the remote control with the help of
the power-switch on the front.
With the power switch turned ON and func-
tioning correctly, the top centre LED on the
remote control will light up red. If the LED con-
trol flashes slowly and an acoustic signal is
heard, the batteries in the controller must be
changed.
Frequency bind between model
and remote control
6
The Carrera RC Quadrocopter and the control-
ler automatically link up renewed with every
operational start-up. If initially there are any
problems with communication between the
Carrera RC Quadrocopter and the remote con-
trol, please carry out a new frequency bind.
• Connect the battery in the model.
• WARNING! Immediately after switching it
on, place the Quadrocopter on a flat and
level surface. The gyro-system will then
set itself automatically.
• The LEDs on the quadrocopter now flash
rhythmically.
ENGLISH
• Switch on the controller at the ON/OFF
switch.
• Push the left-hand joystick, i.e., the throttle
control, completely upwards and then com-
pletely downwards.
• The binding has now been successfully es-
tablished.
• The LED on the controller now lights contin-
uously.
• After approx. 5½ minutes, the controller
switches off. Please repeat the link proce-
dure for renewed use.
Description of the Quadrocopter
7
1. Rotor system
2. Rotor protection cage
3. LEDs
4. Video camera
8
5. Battery compartment
Range of functions of the remote
control
9
1. Power switch (ON / OFF)
2. Control LED
3. Gas
Circling
4. Forwards / backwards
right / left banking
5. Trimmer for right / left banking
6. Trimmer for forwards / backwards
7. Trimmer for rotation
8. Looping Button
9. Headless Mode
10. Start rotor' button
11. 'Auto-landing' button
12. 'Auto-start & fly to 1.5 m' button
13. "LED lights ON/OFF" button
14. Beginner/Advanced switch
(30%/60%/100%)
15. Adaptable tablet holder – button for
adjusting the controller's width
16. Knob for camera angle adjustment
5
17. Battery compartment
