Master/Slave Mode
DIP Number
Function
10+1
R
10+2
G
10+3
B
10+2+1
R+G
10+3+1
R+B
10+3+2
G+B
10+3+2+1
R+G+B
10+8
Automatic mode
10+8+1
R shade
10+8+2
G shade
10+8+3
B shade
10+8+2+1
RGB shade speed 1 fast
10+8+3+1
RGB shade speed 2 mid
10+8+3+2
RGB shade speed 3 slow
10+8+3+2+1
R+G+B shade
10+9
RGB alternate changing
10+9+1
R strobe
10+9+2
G strobe
10+9+3
B strobe
10+9+4
R+B strobe
10+9+5
R+G strobe
10+9+6
G+B strobe
10+9+2+1
R+G+B strobe speed adjust-
ment (DIP 3-7)
10+7
Sound control 1
10+7+1
Sound control 2
10+7+2
Sound control 3
10+7+3
Sound control 4
10+7+4
Sound control 5
10+7+5
Sound control 6
DMX Protokoll
Channel
Function
Value
000 – 015
1
Motor function
016 – 255
2
Motor speed/
000 – 255
Position
000 – 007
Dimmer/
3
strobe
008 – 232
ON/OFF
233 – 255
4
Strobe fre-
000 – 255
quency
000 – 017
018 – 034
035 – 051
052 – 068
069 – 085
086 – 102
103 – 119
Fixed colour/
5
Shade
120 – 136
137 – 153
154 – 170
171 – 187
188 – 204
205 – 221
222 – 238
239 – 255
Shade speed
000 – 255
6
R dimmer
000 – 255
7
G dimmer
000 – 255
8
B dimmer
000 – 255
OFF
000 – 019
020 – 039
040 – 059
060 – 079
Automatic
080 – 099
100 – 119
9
120 – 139
140 – 159
160 – 179
180 – 199
Sound control
200 – 219
220 – 239
240 – 255
Description
Position adjustment via channel 2
Rotation; range adjustment short>long
Fast>slow/
Position (0-170°)
OFF
Strobe slow>fast
ON
Dimmer via channels 6-8
R+G+B
Red
Green
Blue
Yellow
Magenta
Cyan
Red shade
Green shade
Blue shade
White shade
Colour shade
RGB shade 1
RGB shade 2
Fast>slow
R
G
B
OFF
Automatic mode 1
Automatic mode 2
Automatic mode 3
Automatic mode 4
Automatic mode 5
Automatic mode 6
Sound mode 1 R+G+B (strobe)
Sound mode 2 R strobe
Sound mode 3 G strobe
Sound mode 4 B strobe
Sound mode 5
Sound mode 6
Remark
Speed
Adjust-
ment
Via chan-
nel 6
