WXHAP 200 Hot Air Nozzles
Hot Air Nozzles for WXHAP 200
Model
F02
F04
F06
FD2
FD4
R02
R04
R06
R08
R10
M6
2-side heated (Type D)
D04
D06
D08
D10
4-side heated (Type Q)
Q02
Q04
Q06
Q08
SK709
Q10
R01
Subject to technical change without notice.
Type
Flat nozzle
Flat nozzle
Flat nozzle
Dual nozzle
Dual nozzle
Round nozzle
Round nozzle
Round nozzle
Round nozzle, bent
Round nozzle, bent
Adapter
Nozzle
Nozzle
Nozzle
Nozzle
Hot air nozzle
Hot air nozzle
Hot air nozzle
Hot air nozzle
Hot air nozzle
Measuring nozzle
Measuring nozzle
for thermo element
Dimensions A x B
inch mm
.059 x .315 1,5 x 8,0
.059 x .413 1,5 x 10,5
.059 x .472 1,5 x 12,0
Ø .059 x .315 Ø 1,5 x 8,0
Ø .059 x .394 Ø 1,5 x 10,0
Ø .031 Ø 0,8
Ø .047 Ø 1,2
Ø .118 Ø 3,0
Ø .079 Ø 2,0
Ø .079 Ø 2,0
.413 x .413 10,5 x 10,5
.394 x .512 10 x 13
.394 x .591 10 x 15
.394 x .709 10 x 18
.236 x .256 6 x 6,5
.236 x .354 6 x 9
.394 x .591 10 x 15
.492 x .591 12,5 x 15
.472 x .472 12 x 12
.709 x .709 18 x 18
.0197 Ø .0,5
Order-No.
T005 87 277 74
T005 87 277 73
T005 87 277 72
T005 87 277 76
T005 87 277 75
T005 87 278 23
T005 87 278 21
T005 87 278 22
T005 87 277 86
T005 87 277 87
T005 87 617 28
T005 87 277 79
T005 87 277 82
T005 87 277 81
T005 87 277 84
T005 87 277 77
T005 87 277 78
T005 87 277 80
T005 87 277 83
T005 87 278 12
T005 87 277 85
T005 87 278 08
