Model
Power requirement
Operating temperature *
Operating humidity
Power consumption
Dimensions (excluding protrusions)
Weight
* Temperature condition may change when using the monitor together with the optional equipments recommended by SHARP. In such
cases, please check the temperature condition specified by the optional equipments.
As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement
without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from
these values in individual units.

Mounting Precautions (For SHARP dealers and service engineers)

• When installing, removing or moving the monitor, ensure that this is carried out by at least 4 people.
• Be sure to use a wall-mount bracket designed or designated for mounting the monitor.
• This monitor is designed to be installed on a concrete wall or pillar. Reinforced work might be necessary for some materials
such as plaster / thin plastic board / wood before starting installation.
• This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor.
Install by the most suitable method for the material and the structure.
• To attach a mounting bracket, use M6 screws that are 5/16 inch (8 mm) to 3/8 inch (10 mm) longer than the thickness of the
mounting bracket.
• Do not use an impact driver.
• When moving the monitor, be sure to hold it with the handles, the unit bottom and the side of unit. Do not hold the LCD panel.
This may cause product damage, failure, or injury.
• After mounting, please carefully ensure the monitor is secure, and not able to come loose from the wall or mount.
• Do not use any screw holes other than those for mounting brackets, located on the rear of the monitor, for installation.
n R emoving the temporary stand used in the package for transportation
Caution
• The temporary stand used in the package for transportation
is only for use with this monitor. Do not use it for any other
devices.
1. Spread a soft thick cloth (such as a blanket) on a
stable level surface on which the entire monitor can
be placed, and place the monitor on it with the screen
facing down.
2. Remove the stand fixing screws and then remove the
stand.
8
E

Specifications

PN-R903
AC 100 V - 240 V, 7.5 A, 50/60 Hz
32°F to 104°F (0°C to 40°C)
20% to 80% (no condensation)
660 W
inch (mm) Approx. 80-7/8 (W) x 4-13/16 (D) x 47-1/8 (H) (2055 x 122 x 1197)
lbs. (kg) Approx. 165.3 (75) (excluding the temporary stand used in the package
for transportation)
3. Attach the cover (supplied) onto the back of the
monitor.
Secure using 2 cover screws (supplied).
Apply the screw masking sheets (supplied).
Cover screws
(supplied)
Cover
(supplied)
Screw masking
sheets (supplied)
