Graf OPTIMAX Anleitung Seite 8

Installation instructions and maintenance for the
GRAF Optimax
®
Optimax external filter for
green areas (pedestrian
weight resistant)
Order- No 340030
®
Optimax external filter for
light traffic areas
Order- No 340031
The points described in these
instructions must be followed
correctly. If not correctly ob-
served, any right to claim on the
guarantee may be refused. For
all additional GRAF articles pur-
chased there are separate in-
stallation instructions enclosed
in the transportation packing.
Any missing instructions must
be requested directly from us.
A complete check of the tank for
possible damage must be car-
ried out before the installation in
the excavation begins.
The installation must be carried
out by a professional firm.
®
filter external
Contents
1.
General notes
1.1 Safety
1.2 Labelling/Tagging obligation
2.
Installation requirements
®
2.1 Optimax - pedestrian weight resistant
®
2.2 Optimax - light traffic resistant
3.
Transport and storage
3.1 Transport
3.2 Storage
4.
Technical data
5.
Assembly / Installation of external
Filter
5.1 Preparation of the excavation
5.2 Placing in the excavation and laying
the connections
5.3 Telescope installation
5.4 Filling
5.5 Assembly of the extraction mechanism
6.
Commissioning and Service
6.1 Commissioning
6.2 Service
6 / 10
Page 7
Page 7
Page 8
Page 8
Page 9
Page 10
Page 10
Page 10
