Wireless antenna
Factory Default Reset button
There are two ways to reset the router's factory defaults:
1) Use the Factory Defaults function on System Tools -> Factory Defaults page
in the router's Web-based Utility.
2) Use the Factory Default Reset button: First, turn off the router's power. Second,
press and hold the default reset button then turn on the router's power, until the
Systerm LED lights up (about 3 seconds). Last, release the reset button and
wait for the router to reboot.
Note: Ensure the router is powered on before it restarts completely.
RJ45 WAN port for connecting the router to a cable/DSL modem, or Ethernet
Four 10/100Mbps RJ45 LAN ports for connecting the router to the local PCs
AC power socket: only use the power adapter supplied with the RG60SE 108Mbps
Wireless Router, use of a different adapter may result in product damage.
RG60SE 108M Wireless Router User Guide
WAN 1 2 3
RESET
Figure 2-2 Rear Panel sketch
- 5 -
