Plug and Play 8 channel colour
network video recorder
• In the upper strip, select the desired camera then
select "Normal" (permanent recording) or
"Mouvement" (recording on detection of
movement) on the top right. Then draw a square
using the mouse on the half hours to fill or clear
the desired time slot:
• To apply the programming to several
cameras, use the "Copier" (Copy) button at
the bottom of the screen. Click "Suivant" (Next)
to continue.

1.4 - hard disk page

The disk space and its recording time equivalent
are indicated here. The "Ecrasement" (Overwrite)
list lets you choose what happens when the hard
disk becomes full. Select "désactiver" (disable) to
do nothing, select a duration, in days, for automatic
programmed deletion, or "auto" if you wish to
replace the oldest videos with the newest ones, only
if necessary.
Important note: the legal time limit on keeping
video footage is 30 days in France.
Click "Sauver" (Save) to finish the configuration
wizard on your device.
d - CONFigurATiON

2 - GENERAL CONFIGURATION MENU

The menu on your device can be accessed at the
bottom of the main screen: right click on the screen
then click on the "Menu principal" (Main menu)
icon on the left:
The main menu is sub-divided into 6 sections:
• Paramètre (Settings): Set the video inputs
(cameras), video outputs (TV screen, monitor),
settings for video recording, network, motion
detection.
• Recherche vidéo (Video search): menu for
searching and playing back video recordings on
the device's hard disk.
• Appareil (Device): Settings linked to the hard disk
• Système (System): The device's general settings
such as setting the date and time, user accounts
and general information.
• Avancé (Advanced): Maintenance, backup
and configuration restore functions, definition of
alerts should the hard disk become overloaded
or the connection to a camera be lost
• Eteindre (Shut down): Switch the device on or off.

2.1 - SETTINGS SECTION

2.1.1 - "ecran" (screen) tab

Here you will find:
• The IP camera tab that lets you add and list the
cameras paired with your device (same page as
shown in the quick configuration wizard.)
en
11
