Description of the device

Webcam
1
Loudspeaker
2
ON/OFF button
3
Hardware reset
4
4
1 2
Volume buttons
5
Microphone
6
Camera
7
Headphone jack
8
7
3
4
5
6
Micro-USB port
9
Notch
10
Loudspeaker
11
8 9
10
11
