Congratulations on purchasing your Totally Wicked aio Electronic Cigarette Kit.
The Totally Wicked aio is a stylish, exceptionally simple to use e-cigarette design which includes everything
required to begin vaping. Single button, 'push-and-go' functionality ensures optimum simplicity and ease of
use, allowing the user to alter their vaping experience through their choice of atomizer. What's more, the device
incorporates an unparalleled leak resistant cup design with top airflow, meaning the user can simply fill up
with e-liquid and vape without the inconvenience of tiresome spillages. The aio is a fantastic starter kit, which
combines it all in a sleek, ergonomic and hassle-free package, suitable for all e-cigarette users.
Using your aio
Power On and Off:
The aio uses a 5-click on/off function. To switch the device on quickly press the power button 5 times. The LED
within the tank will flash 5 times consecutively, signifying that the device is powered on. Once the aio is powered
on the user can press the button 5 times to switch the device off. Similarly, the LED will flash 5 times.
Vaping:
Simply press the power button as you inhale, the LED will illuminate whilst the device is firing.
Charging the Batteries:
The aio can be charged via the USB cable when connected to a powered USB port or suitable wall adapter. The
tank LED will light up in red to indicate that the battery is charging successfully, the light will power off once fully
charged.
Installing an Atomizer Head:
To install an atomizer head, unscrew the cap from the body of the device
by pushing down on the cap – disengaging the child lock – and turning
it anti-clockwise until the cap is removed. The BF atomizer head can now
be screwed onto the cap in the clockwise direction until firmly sealed on
the silicon O-ring. NOTE: Be sure to drip a few drops of e-liquid into the
atomizer head before the first usage to prevent dry hits, and to ensure its
maximum performance and longevity.
Filling with E-liquid:
To fill the device, remove the atomizer cap as above and fill the tank cavity
with e-liquid. The maximum fill capacity of the tank is indicated by either
where the two colours meet on a bi-colour device, or for a single-colour,
the max fill line is clearly marked on the side of the device. To replace the
atomizer cap, push down on the airflow ring to disengage the child lock
and turn in the clockwise direction until it is firmly in place. NOTE: Please
do not fill beyond the max fill line as this will cause the e-liquid to overflow
once the atomizer and atomizer cap are installed.
Adjustment of Airflow:
To adjust the airflow through the atomizer, simply turn the ring on the
atomizer cap. When the indentation on the ring is aligned with the
indentation just below the mouthpiece, the airflow is fully open. Rotating the
ring either clockwise or anti-clockwise by 90° will fully reduce the airflow, to
find your preferred level of airflow adjust the ring between 0 - 90°.
Battery Life Indication:
The tank LED will stay lit when the battery charge is full, as the level of
charge drops the tank LED will progressively begin to flash more quickly.
The table below can be used as a reference.
Battery Charge Level
60 – 100%
30 – 59%
10 – 29%
0 – 9%
Turn off or Change Tank LED Colour:
When powered off, hold the power button until the LED powers on, then single press the fire button to cycle
through the colours red, yellow, green, blue, indigo, white, purple, or no light showing (stealth mode).
Short Circuit Protection:
If a short circuit occurs before the power button is pressed, the tank LED will flash 5 times consecutively. If a
short circuit occurs while the power button is pressed, the tank LED will flash 3 times consecutively.
Atomizer Protection:
If the power button is pressed for longer than 15 seconds, the device will stop firing and the tank LED will flash
10 times.
Low Voltage Protection:
When the battery voltage drops below 3.3V, the tank LED will flash 40 times and the device will power off.
Charge the device via USB to power it back on.
Kit Contents
1 x aio (1500mAh/2ml)
2 x BF SS316 Atomizer Heads (0.6ohm)
1 x USB Cable
1 x User Manual
DO's
• Store the aio and its accessories away from
children when not in use.
• Ensure the aio is powered off when not in use.
• Avoid accidentally pressing the aio power button
when not in use.
• Please only use the charging cable provided.
• Please dispose of dead batteries in accordance
with your country's appropriate legislation.
Warranty
The aio components have a 28-day parts warranty, with
the exception of Atomizer Heads, which are a consumable
item and covered by "dead on arrival" warranty only. The
USB cable supplied has a 12-month warranty. If any parts
are found to be faulty within this time please contact our
customer service team, whose details are on the back page
of this booklet and we will arrange for a replacement. We may
require the goods to be returned for further investigation.
Light Condition
Continuously Lit
Flashes Slowly
Flashes Moderately
Flashes Quickly
user manual
Specifications
Diameter: 19mm
Length: 118mm
Battery: 1500mAh Li-Battery
Tank: Integrated Tank, 2ml Capacity
Atomizer Type: BF
Atomizer Resistance Capability: 0.3ohm – 5ohm
DON'Ts
• Do not charge the batteries in a damp
environment.
• Do not use the device when temperatures are
outside the range -10 - 60°C.
• Do not charge the battery when temperatures are
outside the range 0 - 45°C.
• Do not attempt to repair a faulty aio as these are
sealed units with no serviceable parts. Attempted
repairs will void the warranty.
