11. Technical Specifications

Tuner
IF Input Frequency
IF Loop through output
IF Input Impedance
Antenna Input Signal Level
LNB Polarization Switching
Voltage
Band Switching
I/Q Output
Demodulator
Symbol Rate
FEC Viterbi
Decoding Rates
Reed Solomon Decoding :
GB
Transport Demultiplexer
De-multiplex
PID Handling Capability
SI Filtering
Video Decoding Parameters
Video Decoding
Aspect Ratio
Resolution
Audio Decoding Parameters
Audio Decoding
Operating Mode
Sampling Frequency
Base band Video/Audio Output
Video Output Impedance
Video Output Level
Audio Output Impedance
Audio Output Level
Digital Audio Output Level
Microprocessor and Main Memories
Microprocessor Type
Flash ROM
(for program memory)
SDRAM (for decoding)
950 ~ 2,150 MHz
950 ~ 2,150 MHz
75 ohm
-65dbm ~ -25dbm
13/18 V DC @ Max
400mA, short circuit
protected
22 kHz tone, DiSEqC
1.2, USALS
Unbalanced Output,
Controlled by AGC
Input
QPSK
1 ~ 45 Msps
1/2, 2/3, 3/4, 5/6, 7/8
FEC 204,188, t=8
According to ISO /
IEC 13818-1
32 PID
According to DVB-SI
spec (ETS 300 468)
ISO / IEC 13818-2
MP@ML
4:3, 16:9
Max. 720 x 576 dots
ISO / IEC 13818-3
Layer I & II
Mono, Stereo
32, 44.1, 48 kHz
75 ohm
1Vp_p
600 ohm
(unbalanced)
3.0 Vp_p (with
volume control)
0.5 Vp-p (across 75
ohm)
ST20 -C2 (STI 5518)
1 MB (16-bit)
4 MB (16-bit)
DVB S1
Data Service Port
Connector
Protocol
Data Rate
Front Panel
4-Digit LED Display
8 Buttons
IR Sensor
Rear Panel
IF Input
IF Loop-Through
Output
AUDIO (left, right)
VIDEO
Digital Out (SPDIF)
TV
VCR
S-Video
Optischer Ausgang
RS-232 Serial Port
Remote Control Unit
Type
Battery
35 keys
General Data
Power Supply
Power Consumption
Dimension
(W x D x H)
Weight
All rights reserved
9 Pin D-sub Female
Type
RS-232
(asynchronous)
115,200 bps (max.)
Channel number /
clock time display
Power, Down, Up,
Left, Right, Menu,
Exit, OK
38 kHz
F-type, female
F-type, female
Cinch (RCA)
Cinch (RCA)
Cinch (RCA)
SCART (21 pole)
SCART (21 pole)
Hosiden
Toslink
9 Pin D-sub Female
Type
IR (Carrier Freq.
38 kHz)
2 x 1.5 V (AAA size)
Power, Mute, 0~9,
Page-up, Page-down,
Exit, Menu
CH-UP, CH-DN, Left,
Right, OK, Info, EPG,
F1,F2, Vol-UP, Vol-
DN, TV / Radio, Last,
Freeze, Audio,
95 ~ 250 volts AC
30 watts (max.)
340 x 255 x 68 mm
2.5 kg
