5. Getting Started

This chapter explains some settings you will need to make before using the receiver for the first time.
For easier operation the most popular TV and radio channels of ASTRA, HotBird and TURKSAT
satellite have been factory-preset.
You may change the pre-programmed channel list or its sorting at any time.

5.1 Connecting the Satellite Receiver

Mains Supply
This unit is designed for any common mains voltage (95 ~ 250 volts, no adjustment needed).
TV Set
Connect the TV SCART connector on this satellite receiver to the SCART connector of your TV set,
using a commonly available 21-pole SCART cable.
Antenna
Connect the coaxial cable from your satellite antenna system (LNB) to the IF INPUT connector of
the satellite receiver.
For details, please refer to section "Rear Panel Connections".

5.2 First Steps

Press the button on the remote control or on the
receiver. "ON" appears on the front display of the receiver and
the language selection menu appears on your TV. Use the
and buttons on the remote control or on the receiver to
select the language of your choice and then press the OK
button. When selecting ENGLISH, a
appears on your TV screen:
Your Digital Satellite Receiver is factory pre-programmed.
After you have adjusted several settings in the GENERAL
SETTINGS menu you have to press [EXIT] for loading the
pre-programmed channel data.
If you don't want to use this data press [MENU] and select
Channel Manager to start your own searching.
Press OK to enter the "General Settings" menu.
In the "General Settings" menu you can perform individual
settings that are related to the local time zone (summertime
included), your TV set, and desired language selections. For
adjustments, please use the
explanations at the bottom of the menu screens.
- Press EXIT for loading the pre-programmed channel data. That may take some 30 seconds.
(Please wait.)
or
- Press MENU for selecting the "General Settings" menu. Then select " 3. Channel Manager"
and perform item "1. Auto Search" or item "2. Manual Search", according to your needs.
WELCOME screen
and buttons and see the
