Set the channel's Video PID.
Set the channel's Audio PID.
Set the channel's PCR PID.
Press the OK button at "Start Search"
The names of the channels will be listed.
Press the EXIT button to return to viewing mode and check that the reception of the selected
channel is good.

9.8 Transponder Editor

The "Transponder Editor" allows you to change, add, and
delete satellite information.
Go to the "Main Menu", select "Channel Manager", select
"Transponder Editor", and then press the OK button.
Add a Satellite
Use the
Press the OK button. The screen will change to allow you to
enter the name of the satellite you are adding.
Use the
change the cursor position.
GB
When you have finished entering the satellite name, press
OK.
Press the OK button to enter the added satellite's TP
information of the added satellite.
When the TP information input field appears in the right
panel, press the OK button.
Enter the TP information, such as Frequency, Polarization (H / V), Symbol Rate, etc., and then
press the OK button. (Use the Numeric buttons to enter Frequency and Symbol Rate
information, and use the
To cancel the entries you have made, press the BACK button or the EXIT button.
Delete a Satellite
Use this to delete the selected satellite. However, you won't be able to delete any of the
satellites, which were set as factory defaults.
Use the CH UP and CH DOWN buttons to select the satellite you want to delete.
Press the
If you want to delete, press the OK button.
Otherwise, press the "Back" button or the EXIT button.
Modify Satellite TP Information
To modify the TP information, move to the satellite you want and then press the OK button.
The satellite TP information appears on the right side of the screen.
Select the TP information you want to modify and then press the OK button.
Modify the TP information, such as Frequency, Polarization, Symbol Rate, etc., and then
press the OK button. (Use the Numeric buttons to enter Frequency and Symbol Rate
information, and use the
After the changes are made, press the OK button to update the TP information.
To cancel the TP information modification process, press the BACK button.
Add Satellite TP Information
Move to the bottom of the screen where the satellite TP information is displayed and then
press the OK button.
Enter the TP information you want to add, such as Frequency, Polarization (H / V), Symbol
Rate, etc. (Use the Numeric buttons to enter Frequency and Symbol Rate information, and
use the
Press the OK button to register the TP information.
To cancel the TP information addition process, press the BACK button.
buttons to move to the last field on the list.
buttons to enter letters. Use the
buttons to enter H / V information).
button. A message appears, asking for your confirmation.
buttons to enter H / V information).
buttons to enter H / V information).
DVB S1
buttons to
