Setup Manual Important: Please read this Setup Manual and the User’s Manual stored (on the CD- ROM) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. Installationshandbuch Wichtig: Lesen Sie dieses Handbuch zur Einrichtung und das Benutzerhandbuch (auf der CD-ROM) aufmerksam durch, um sich mit der sicheren und effizienten Bedienung vertraut zu machen. Bewahren Sie dieses Handbuch zum späteren Nachschlagen auf. Manuel d’installation Important : Veuillez lire attentivement ce Manuel d’installation et le Manuel d’utilisation (inclus sur le CD-ROM) afin de vous familiariser avec ce produit et de l’utiliser efficacement et en toute sécurité. Veuillez conserver ce manuel pour référence ultérieure. 设定手册 重要事项: 请仔细阅读本设定手册和用户手册(储存在光盘上),以便掌握如何安全、 有效地使用本产品。请保留本手册,以备日后参考。...
Seite 2
EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
Seite 3
A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
Seite 4
This product does not include a power cord. Please provide separately a power cord which meets the requirements. (For more information, please contact your local EIZO representative.) • The power cord is compatible with the standards of the country and region in which this product is to be used.
Seite 5
Not doing so may cause the unit to become unattached, which may result in injury or equipment damage. When the unit is dropped, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
• EIZO LCD Utility Disk (CD-ROM) • Setup Manual (this manual) Attention • This product does not include a power cord. Please provide separately a power cord which meets the usage requirements. For more information, please contact your local EIZO representative. Controls and Functions Setting menu button Switches input signals for display.
Connecting Cables Attention • Check that the monitor and the PC are powered off. • When replacing the current monitor with this monitor, be sure to change the PC settings for resolution and vertical scan frequency to those that are available for this monitor. Refer to the compatible resolution table (page 1) before connecting the Note •...
Seite 8
Displaying the Screen Press to turn on the monitor. The monitor’s power indicator lights up blue. Turn on the PC. The screen image appears. If an image does not appear, refer to “No picture” (page 9) for additional advice. If using the FDSV1201T proceed with installation and calibration of the touch panel driver. Attention •...
Seite 9
Installing the Touch Panel Driver (FDSV1201T) Attention • The user account to be used for installing the touch panel driver must have the “Administrators” privilege. • When reinstalling the touch panel driver to update the driver, etc., restart the PC after uninstalling the driver and then install Uninstall the other touch panel driver, if it is installed.
Troubleshooting ● No picture If a problem still remains after applying the suggested remedies, contact your local EIZO representative. Problem Possible cause and remedy 1. No picture • Check whether the power cord is connected properly. • Power indicator does not light. • Press . • Power indicator is lighting blue. • Increase “Brightness” and/or “Gain” in the Setting menu. • Power indicator is lighting orange.
Seite 11
*1 PDF-Datei auf CD-ROM (Erfordert die Installation von Adobe Reader.) Kein Teil dieses Handbuchs darf ohne die vorherige schriftliche Zustimmung von EIZO Corporation in irgendeiner Form oder mit irgendwelchen Mitteln – elektronisch, mechanisch oder auf andere Weise – reproduziert, in einem Suchsystem gespeichert oder übertragen werden.
Seite 12
Ein an einer ungeeigneten Stelle aufgestelltes Gerät kann herunterfallen und dabei Verletzungen oder Geräteschäden verursachen. Fällt das Gerät herunter, ziehen Sie sofort das Netzkabel ab, und wenden Sie sich an Ihren lokalen EIZO-Handelsvertreter. Arbeiten Sie nicht mit einem beschädigten Gerät, da Brand- und Stromschlaggefahr besteht.
Seite 13
Achten Sie darauf, dass das Netzkabel die folgenden Anforderungen erfüllt. Ein Netzkabel gehört nicht zum Lieferumfang dieses Produkts. Benutzen Sie bitte ein Netzkabel, dass die Anforderungen erfüllt. (Für weitere Informationen wenden Sie sich bitte an Ihren lokalen EIZO- Handelsvertreter.) • Das Netzkabel entspricht den Standards in dem Land und in der Region, wo das Produkt verwendet werden soll.
Seite 14
Andernfalls kann es herunterfallen und dabei Verletzungen oder Schäden am Gerät verursachen. Sollte das Gerät heruntergefallen sein, wenden Sie sich an Ihren lokalen EIZO-Handelsvertreter. Arbeiten Sie nicht mit einem beschädigten Gerät. Die Verwendung eines beschädigten Geräts kann Feuer oder einen Stromschlag verursachen.
• EIZO LCD Utility Disk (CD-ROM) • Installationshandbuch (das vorliegende Handbuch) Beachte • Ein Netzkabel gehört nicht zum Lieferumfang dieses Produkts. Benutzen Sie bitte ein Netzkabel, dass die Anforderungen erfüllt. Für weitere Informationen wenden Sie sich bitte an Ihren lokalen EIZO-Handelsvertreter. Bedienelemente und Funktionen Einstellungsmenü Taste Schaltet zwischen den Eingangssignalen für die Anzeige um.
Kabel anschließen Beachte • Stellen Sie sicher, dass Computer und Monitor ausgeschaltet sind. • Wenn der vorhandene Monitor durch diesen Monitor ersetzt wird, müssen auf jeden Fall die PC-Einstellungen für die Auflösung und die vertikale Abtastfrequenz auf diejenigen umgeändert werden, die für diesen Monitor verfügbar sind. Ziehen Sie vor dem Anschließen des PCs die Tabelle Kompatible Auflösung (Seite 1) zu Rate.
Seite 17
Bild wiedergeben Drücken Sie , um den Monitor einzuschalten. Die Netzkontroll-LED des Monitors leuchtet auf (blau). Schalten Sie den Computer ein. Das Bildschirmbild erscheint. Falls kein Bild erscheint, siehe „Kein Bild“ (Seite 9) für weitere Hilfe. Bei Verwendung des FDSV1201T fahren Sie mit der Installation und Kalibrierung des Touch-Panel-Treibers fort.
Installieren des Touch-Panel-Treibers (FDSV1201T) Beachte • Das Benutzerkonto, das zum Installieren des Touch-Panel-Treibers verwendet werden soll, muss „Administrator“-Rechte aufweisen. • Wenn Sie den Touch-Panel-Treiber z. B. zum Aktualisieren des Treibers neu installieren, starten Sie den PC nach der Deinstallation des Treibers neu, und installieren Sie den Treiber erst dann. Deinstallieren Sie ggf.
Fehlerbeseitigung ● Kein Bild Besteht ein Problem auch nach Anwendung aller angegebenen Lösungen, wenden Sie sich an einen lokalen EIZO-Handelsvertreter in Ihrer Nähe. Problem Mögliche Ursache und Lösung 1. Kein Bild • Prüfen Sie, ob das Netzkabel ordnungsgemäß • Die Netzkontroll-LED leuchtet nicht. angeschlossen ist. • Drücken Sie . • Die Netzkontroll-LED leuchtet blau.
Seite 20
EIZO Corporation n’est tenu à aucun engagement de confidentialité sauf en cas d’accord préalable passé avant la réception de ces informations par EIZO Corporation. Malgré tous les efforts déployés pour garantir la mise à jour des informations contenues dans ce manuel, veuillez noter que les caractéristiques techniques du moniteur EIZO sont...
Seite 21
Il y a risque de chute de l’appareil sur une surface inappropriée, qui pourrait entraîner des blessures ou endommager l’appareil. En cas de chute, débranchez immédiatement le cordon secteur et demandez conseil à votre représentant local EIZO. Toute utilisation de l’appareil après une chute peut entraîner un incendie ou un choc électrique.
Seite 22
Ce produit n’inclut pas le cordon d’alimentation. Veuillez fournir séparément un cordon d’alimentation répondant aux exigences. (Pour en savoir plus, veuillez contacter votre représentant local EIZO.) • Le cordon d’alimentation se conforme aux normes du pays et de la région dans lesquels ce produit doit être utilisé.
Seite 23
Un mauvais montage pourrait se traduire par une séparation de l’appareil qui pourrait l’endommager ou causer une blessure. Si l’appareil a subi une chute, demandez conseil à votre représentant local EIZO. Toute utilisation de l’appareil après une chute peut entraîner un incendie ou un choc électrique. Pour refixer le socle inclinable, utilisez les mêmes vis et serrez-les correctement.
• Câble de signal analogique: MD-C87 • EIZO LCD Utility Disk (CD-ROM) • Manuel d’installation (ce manuel) Attention • Ce produit n’inclut pas le cordon d’alimentation. Veuillez fournir séparément un cordon d’alimentation répondant aux exigences. Pour en savoir plus, veuillez contacter votre représentant local EIZO. Commandes et fonctions Menu de réglage 1. Touche Commute les signaux d’entrée de l’affichage 2.
Branchement des câbles Attention • Vérifiez que le moniteur et le PC sont hors tension. • Lorsque vous remplacez le moniteur actuel par ce moniteur, veillez à modifier les réglages de votre ordinateur en fonction de la résolution et de la fréquence de balayage vertical propres à ce moniteur. Reportez-vous au tableau des résolutions compatibles (page 1) avant de brancher l’ordinateur.
Affichage de l’écran Appuyez sur pour mettre le moniteur sous tension. Le témoin de fonctionnement du moniteur s’éclaire en bleu. Mettez le PC sous tension. L’image affichée à l’écran apparaît. Si une image n’apparaît pas, reportez-vous à la section « Aucune image » (page 9) pour savoir comment procéder.
Seite 27
Installation du pilote de l’écran tactile (FDSV1201T) Attention • Le compte d’utilisateur à utiliser pour l’installation du pilote de l’écran tactile doit disposer de droits d’« Administrateurs ». • Lorsque vous souhaitez réinstaller le pilote de l’écran tactile pour le mettre à jour, etc., redémarrez l’ordinateur après avoir désinstallé...
Dépannage ● Aucune image Si un problème persiste après application des corrections proposées, veuillez prendre contact avec votre représentant local EIZO. Problème Cause possible et solution 1. Aucune image • Vérifiez que le cordon d’alimentation est correctement • Le témoin de fonctionnement ne s’allume branché. pas. • Appuyez sur . • Le témoin de fonctionnement s’allume en • Augmentez les valeurs de « Luminosité » et/ou « Gain »...
