Technische Informationen
Kontaktbelegung
Digitaler Videoeingang: DVI – D (Option)
TX2-
1
TX2+
2
Shield (TX2 / TX4)
3
NC
4
NC
5
6
DDC-Serial Clock
DDC-Serial Data
7
8
NC
PIN
Description
1
Red
2
Green
3
Blue
4
GND
5
Detect
6
Red_GND
7
Green_GND
8
Blue_GND
9
TX1-
10
TX1+
Shield (TX1 / TX3)
11
12
NC
NC
13
+5V power
14
Ground (+5V)
15
16
Hot plug detect
9
Signal
PIN
Description
9
+5V
10
GND
11
GND
12
DDC_SDA
13
HSYNC
14
VSYNC.
15
DDC_SCL
17
TX0-
18
TX0+
Shield (TX0 / TX5)
19
20
NC
NC
21
22
Shield (TXC)
23
TXC+
TXC-
24
