DESCRIPTION OF THE DEVICE
Features
RGBW Moving Head Beam with two separately controllable LED heads and unlimited PAN movement
• With Infinity function for unlimited PAN movement
• TILT movement for each LED head separately and steplessly adjustable
• Equipped with two 10 W quadcolor LEDs (CREE) with RGBW colors
• Each LED can be controlled individually
• Flicker-free projection
• Narrow beam angle
• Compact lightweight
• 17 or 24 DMX channels selectable
• Functions: Colored beams in R, G, B and W, auto mode, sound control, color presets, strobe settings,
Master/Slave function, built-in programs
• Stepless RGBW color changing
• Dimmer
• Strobe effect with adjustable speed
• Random strobe effect
• Exact positioning via 16 bit PAN/TILT movement resolution
• DMX-controlled operation or stand-alone operation with Master/Slave function
• Sound-controlled via built-in microphone
• Addressing via control panel with 4-digit LED display
• Switch-mode power supply for operation between 100 and 240 Volts
• Feed-through output allows to power up to 8 devices
• Ready for connection with power cord and safety plug
• DMX512 control possible via any commercial DMX controller
Overview
(1) Yoke
(2) Projector head
(3) LED/lens
(4) Control Board
(5) Menu button
(6) Up-button
(7) Down-button
(8) Enter-button
(9) Display
(10) Base
21/31
00092157, Version 1.2
