Rear connectors

Stereo Speaker Stereo Speaker
V DC 9V DC 9V DC
12V DC
Connect to supplied
mains adapter only

Remote control

Volume
Increase and
decrease the
volume
Presets 1 − 5+
Store up to 15
digital and 15
FM radio preset
stations (see
page 10)
Stereo Speaker
3.5 mm stereo
headphone socket
Aux in Aux in Aux in
Aux in
Analogue stereo
input for iPod,
MP3 player, etc
Standby
Switch the radio between
sleep, standby or off if a
ChargePAK is fitted (see
page 6)
<Select>
Press to browse and select
radio stations (see page 8)
or pause and control scrolling
text (see page 9)
EN
Mini-B type USB
connector for
upgrades only
5
