Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.

OPERATION

After you connected the effect to the mains, the LED PST-10 QCL Scan Light starts running. During the
Reset, the motors are trimmed and the device is ready for use afterwards.

Stand Alone operation

In the Stand Alone mode, the LED PST-10 QCL Scan Light can be used without controller. You can do
without a controller as the LED PST-10 QCL Scan Light features a built-in microphone, which provides
automatic sound control.
You can adjust the sensitivity with the rotary-control.
Disconnect the LED PST-10 QCL Scan Light from the controller and select the desired "Master Mode".
Master/Slave-operation
The master/slave-operation enables that several devices can be synchronized and controlled by one master-
device.
On the rear panel of the LED PST-10 QCL Scan Light you can find an XLR-jack (DMX Out) and an XLR-plug
(DMX In), which can be used for connecting several devices.
Choose the device which is to control the effects. This device then works as master-device and controls all
other slave-devices, which are to be connected to the master-device via a balanced microphone lead.
Connect the DMX OUT-jack with the DMX IN-plug of the next device.
Set the desired Master-mode for the master-device (G-1- or G-2-).
Set the desired Slave-mode for all slave-devices (S-1-, S-2-, S-3-, or S-4-)..
The Slave devices are now linked with the Master device in such a way, that they play back the Master
program – as Chaser (continuous loop) – in series.
Please refer to further instructions under Control Board.
