PC70EE, PC70VEE, PC70HEE, PC70VHEE, PC90EE, PC90VEE, PC90HEE, PC90VHEE Instructions for Installation and Use of Electric Sauna Heater Gebrauchs- und Montageanleitung des Elektrosaunaofens Адрес: ООО «Харвия РУС». 196084, г. Санкт-Петербург, ул. Заставская, дом 7 E-mail: regionlog12@mail.ru PCEE PCVEE PCHEE PCVHEE 29072016/ZSC-198...
These instructions for installation and use are Diese Montage- und Gebrauchsanleitung richtet intended for the owner or the person in charge of sich an den Besitzer der Sauna oder an die für die the sauna, as well as for the electrician in charge Pflege der Sauna verantwortliche Person, sowie an of the electrical installation of the heater.
1. INSTRUCTIONS FOR USE 1. BEDIENUNGSANLEITUNG 1.1. Piling of the Sauna Stones 1.1. Aufschichten der Saunaofensteine The piling of the sauna stones has a great effect Die Schichtung der Saunaofensteine hat große Aus- on both the safety and the heating capability of the wirkungen sowohl auf die Sicherheit als auch auf heater.
that could change the amount or direction of Schichten Sie die Steine oben auf dem Ofen • the air flowing through the heater. nicht zu einem hohen Stapel auf. In der Steinkammer oder in der Nähe des • A bare heating element can endanger Saunaofens dürfen sich keine Gegenstände combustible materials even outside the safety oder Geräte befinden, die die Menge oder die...
1.5. Instructions for Bathing 1.5. Anleitungen zum Saunen Begin by washing yourself. Waschen Sie sich vor dem Saunen. • • Stay in the sauna for as long as you feel Bleiben Sie in der Sauna, solange Sie es als • •...
Additional settings/WEITERE EINSTELLUNGEN Heater standby Standby des Ofens Switch the power off from the main Schalten Sie den Strom am Hauptschalter ab switch (see figure 7). Press and hold the (siehe Abbildung 7). Halten Sie die MENU- MENU button, then switch the power on Taste gedrückt und schalten Sie den Strom am from the main switch.
1.6. Warnings 1.6. Warnungen Staying in the hot sauna for long periods of Ein langer Aufenthalt in einer heißen Sauna • • time makes the body temperature rise, which führt zum Ansteigen der Körpertemperatur, may be dangerous. was gefährlich sein kann. Keep away from the heater when it is hot.
Seite 9
Check the sauna stones ( 1.1.). Too tightly Überprüfen Sie, ob die Ofenleistung ausrei- • • piled stones, the settling of stones with time chend ist ( 2.3.). or wrong stone type can hinder the air flow Überprüfen Sie die Saunaofensteine ( 1.1.). Eine •...
2. SAUNA ROOM 2. SAUNAKABINE 2.1. Sauna Room Structure 2.1. Struktur der Saunakabine Figure 4. Abb. 4. A. Insulation wool, thickness 50–100 mm. The A. Isolierwolle, Stärke 50–100 mm. Die Saunaka- sauna room must be insulated carefully so that bine muss sorgfältig isoliert werden, damit der the heater output can be kept moderately low.
2.2. Sauna Room Ventilation 2.2. Belüftung der Saunakabine The air in the sauna room should change six times Die Saunaluft sollte sechsmal pro Stunde ausge- per hour. Figure 5 illustrates different sauna room tauscht werden. Abb. 5 zeigt verschiedene Optio- ventilation options.
the sauna floor must be approved for use in a räte, die höher als 1 000 mm vom Saunaboden temperature of 125 °C (marking T125). angebracht werden, müssen für den Gebrauch In addition to supply connectors, the heaters are bei 125 °C Umgebungstemperatur zugelassen •...
The sensor must be installed to the place defined Luftzufuhr weist vom Fühler weg: 500 mm • in these instructions (figure 8). If the minimum Der Fühler muss an der Stelle angebracht wer- den, die in diesen Anweisungen angegeben wird distance is not fulfilled, ventilation must be changed.
Seite 16
3.3. PCEE/PCVEE PCHEE/ PCVHEE Figure 9. Installing the heater Abbildung 9. Installation des Saunaofens Figure 10. Reset button for overheat protector Abbildung 10. Rücksetzknopf des Überhitzungsschutzes...
