SPECIFICATIONS

Model MX-B200
Type Digital multifunctional system, desk-top type
Copy / printer system Dry, electrostatic transfer
Originals Sheets, bound documents
Printer function Available
Scanner function Available
Paper tray 250 sheets
Multi-bypass tray 50 sheets
Paper output tray 200 sheets *
Original Document
Max. A4
sizes glass/SPF
Document
1 sheet
Original
glass
feed
SPF Up to 50 sheets
Copy / printing size A6 to A4*
Max. 4 mm *
Image loss
Max. 4.5 mm *
Copy speed 20 pages/min. (A4)
5
Print speed * 20 pages/min. (A4)
Continuous copying Max. 99 pages subtractive counter
First-copy time * 6 8.0 seconds (When user program 24 is set to OFF)
(Approximately) 10.7 seconds (When user program 24 is set to ON)
Warm-up time * 7
-
(Approximately)
Variable: 25% to 400% in 1% increments
Document
glass
Fixed:
Copy
ratio
Variable: 50% to 200% in 1% increments
SPF
Fixed:
Document Moving optical source, slit exposure (stationary
Exposure
glass platen) with automatic exposure
system
SPF Moving original
Fusing system Heat rollers
Development system Magnetic brush development
Light source Cold cathode fluorescent lamp
600 x 300 dpi (Auto/Manual mode)
Copier
600 x 600 dpi (Photo mode)
Resolution
Printer 600 dpi
Scanner 600 x 600 dpi
Scan 256 levels
Gradation
Output 2 levels
Bit depth 1 bit or 8 bit/pixel
Sensor Colour CCD
Scanning speed Max. 2.88 ms/line
Memory 32 MB
Local voltage ±10% (For this machine's power
Power supply supply requirement, see the name plate located
on the back of the machine.)
Power consumption Max. 1.0 kW
Width 802 mm
Overall
dimensions
Depth 445 mm
Weight (Approximately) * 8 15.9 kg
Width 518 mm
Unit
Depth 445 mm
dimensions
Height 298 mm
Temperature: 10°C to 30°C
Operating conditions
Humidity: 20% to 85%
SHARP SPLC
Emulation
(Sharp Printer Language with Compression)
Interface port USB interface (USB 2.0 Hi Speed)
1
2
3
4
(total 376 steps)
50%, 70%, 86%, 100%, 141%, 200%
(total 151 steps)
50%, 70%, 86%, 100%, 141%, 200%
Sound power level L
Copying mode: 6.4 B
Standby mode: 3.5 B
Sound pressure level L
Copying mode: 47 dB
Noise level Standby mode: 19 dB
Sound pressure level L
Copying mode: 52 dB
Standby mode: 19 dB
Noise emission measurement in accordance
with ISO7779.
*1 When standard A4 paper is used under the operating conditions.
*2 Feed paper lengthwise only.
*3 Leading and trailing edges.
*4 Along the other edges in totals.
*5 Print speed during printing of the second sheet and following sheets
when using A4 plain paper in the tray 1 and performing continuous one-
sided printing of the same page.
*6 First copy time may vary depending on the status of the machine.
*7 Warm-up time may vary depending on some environments.
*8 Not including toner cartridge.

Optional equipment

Single pass feeder (MX-SP10)
Weight: 56 g/m
Acceptable originals Size: A5 to A4
Capacity: Up to 50 sheets
Power supply Drawn from the unit.
Weight
2.3 kg
(Approximately)
Dimensions 496 mm (W) x 359 mm (D) x 89 mm (H)
250-sheet paper feed unit (MX-CS10)
Paper size A5 to A4
Paper weight 56 g/m
One paper tray with capacity for 250 sheets of
Paper capacity
80 g/m
Weight 3.0 kg
Dimensions 498 mm (W) x 445 mm (D) x 87 mm (H)
Power supply Drawn from the unit
As a part of our policy of continuous improvement, SHARP
reserves the right to make design and specification changes for
product improvement without prior notice. The performance
specification figures indicated are nominal values of production
units. There may be some deviations from these values in
individual units.
wAd
(reference) (Bystander positions)
pAm
(reference) (Operator position)
pAm
2 2
to 90 g/m
2 2
to 80 g/m
2 paper
3
