IR-320 Specifications
CPU
Power management
DIMM sockets
System ROM
Chipset
Video controller
Sound
Speaker
Parallel
Serial
Ethernet
Keyboard/mouse
Display
USB
Drawer (DK)
External TM power
supply
PCI slot
Floppy disk drive
Hard disk drive
CD-ROM drive (option)
CD-R/RW drive (option)
TM
Intel: Celeron 733 MHz (FCPGA) Secondary cache 128 KB built-in
TM
Intel: Celeron 1.2 GHz (FCPGA2) Secondary cache 256 KB built-in
IR-320 BIOS supports Advanced Configuration and Power Interface (ACPI).
ACPI controls power management function for the CPU, video, hard disk drive, and
so on.
Two 168-pin DIMM sockets are provided on the main board.
3.3V SDRAM / maximum 512 MB
System BIOS and video BIOS are registered in 4 MB flash ROM on the main board.
Intel 810E2
Built-in Chipset, 1024 × 768 (16 M colors), 800 × 600 (16 M colors),
640 × 480 (16 M colors). Color available only when a CRT is connected.
Can be output to the built-in speaker. External line input/output, microphone input
Built-in monaural speaker with volume control
25-pin D-Sub female connector. Port can be defined as ECP or EPP.
9-pin D-sub male connector × 2. Six serial ports supported. 2 ports used for internal
printer/DM display (COM3) and touch panel (COM4). When either COM5 or COM6
is used, an unneeded device (such as Parallel, USB, or Sound) must be set to unused
by BIOS setup.
10BASE-T or 100BASE-TX Wake Up on LAN available
6-pin miniature-DIN female connector (PS/2 type). Use branch (Y cable) to connect
both keyboard and mouse.
15-pin SD-Sub female connector. Analog RGB display can be connected.
The CRT and the LCD can be displayed at the same time. However, the CRT and
the LCD cannot display different screens with the multi-display function of

Windows 98 (Second Edition) / Windows
Professional Edition. To use the multi-display function, install a video card in the PCI
slot and connect the monitor to the video card.
Type A 4-pin × 2. One USB at the rear side and one on the right side. The USB
interface supports Windows

Windows XP Professional Edition.
6-pin. When a printer is attached, a cash drawer can be connected to this
interface.
One port (24V) When the IM-320 is equipped with a dedicated TM printer, the
power connector for the external TM printer cannot be used.
PCI slot × 2. 32-bit, half-size: 135 × 101 mm {5.3 × 4.0"} (L × W), H: Parts side:
12 mm {0.47"}, H: solder side 10 mm {0.39"} I/O expansion slots. +3.3V is available.
3.5-inch floppy disk drive with a 720 KB or 1.44 MB storage capacity.
A unit of 3.5"-type Hard Disk (maximum thickness: 25.4 mm {1"}) or 2 units of the 2.5"-
type Hard Disk (maximum thickness: 9.5 mm {0.37"}, for a unit: 12.7 mm {0.5"}
maximum) can be attached. IDE interface, Ultra DMA/33/66/100.
E-IDE Interface. Can be set as boot drive. Cannot be installed when a Front
CompactFlash Adapter is installed.
E-IDE Interface. Can be set as boot drive. To write to the CD-R or CD-RW,
commercially available software is necessary. Cannot be installed when a Front
CompactFlash Adapter is installed.

2000 Professional / Windows

98 (Second Edition) / Windows

XP

2000 Professional /
