For poorly reflecting surfaces (e.g. dark window /
door frames) the supplied reflecting sticker has to
be fixed to the inner edge of the window / door
casement on the opposite of the infra-red sensor
(F) or the window / door contact.
5.2.2

Adhesive strip or screw mounting

You can mount the window / door contact with
• the double-sided adhesive strip or
• countersunk head screws
to the window / door frame.
Adhesive strip mounting
For mounting the window / door contact with the sup-
plied adhesive strip, please proceed as follows:
• Attach the double-sided adhesive strip to the
back of the electronic unit (B) and press the elec-
tronic unit onto the desired position of the win-
dow / door frame (see figure 6).
Make sure that the mounting surface is smooth,
solid, non-disturbed, free of dust, grease and sol-
vents and not too cold to ensure long-time ad-
herence.
