Function and device overview

The Homematic IP Door / Window Contact detects open
and closed windows and doors by an integrated infra-red
sensor.
Open windows and doors are immediately displayed in the
Homematic IP app. Even while being away from home you
can keep a close eye to your windows and doors.
Thanks to the two different caps, the colour of the device
adapts to the door and window frames. Furthermore, the
window / door contact can be easily mounted thanks to
the supplied adhesive strips or screws.
Thanks to the integrated tamper contact you are imme-
diately informed via the app about manipulation of the
door / window contact.
Strong extraneous light and contamination of the
sensor can lead to functional disorders.
Device overview (see figure 1):
(A)
Bore holes
(B)
Electronic unit
(C) Battery compartment
(D)
Cap
(E)
System button (teach-in button and LED)
(F) Infra-red sensor
Function and device overview
