Luda tractorCam Bedienungsanleitung Seite 30

Left/Channel 4
Down/Channel 3
QUAD button
Notice! Before use, remove plastic protective film in battery compartment.
The mounting foot is delivered in
two parts. Fit them toghether with
the supplied screws as above.
Mounting foot for 7" LCD-monitor.
(Art. no 7008)
30
Up/Channel 1
Remote control for 7" LCD-monitor. (Art. no 7007)
Menu
Right/Channel 2
Scan button
Power On/Off
Lighter socket power adapter
(Art. no 6015)
Trigger cable
(Art. no 6021)
Direct power cable
(Art. no 6014)
