1. General Notes

1.1 Brief description

The EURO X LED is a self con-
tained exit sign luminaire for
the designation of escape rou-
tes (integral lithium ion battery).
The luminaire is equipped with
an automatic testing function,
meaning battery operation is
tested once weekly and bat-
tery capacity twice yearly. Test
results are displayed via a dual
colour LED.
The luminaire is universally sui-
table for wall and ceiling moun-
ting and has IP54 protection
rating.
It is designed for installation
indoors.

2. Safety notes

• The luminaire shall only be
used for its intended purpose

4. Technical data

Viewing distance
rated operation time
Luminous flux at the end of rated operating
time
Housing material
Housing colour
Type of mounting
Dimensions in mm (L x B x H)
Weight
Voltage ranges
Supply terminals
Power consumption mains operation
(apparent power/active power)
Light source
Battery
Insulation class
Protection category
Permissible temperature
8
and in an indamaged and per-
fect condition!
• Only genuine CEAG spare
parts may be used for replace-
ment and repair!
• When working on the emer-
gency luminaire first cut off
mains and interrupt battery
operation.
• Prior to its initial operation,
the luminaire will have to be
checked in accordance with
the instructions as per section

'Installation'!

• Carry out the marking of the
emergency luminaire:
Assign the circuit and the lumi-
naire no. and enter them. (Note
maintained or non-maintained
mode on the type label [0/1]).
• The manual log book shall be
performed in compliance with
the national regulations.
20 m
3 h
50 %
Polycarbonat
white
Wall mounting, Ceiling mounting
230 x 60 x 163
0.44 kg
220 - 240 V, 50/60 Hz
plug-in terminal / mains L, N, PE 0.5 - 2.5 mm²
8.9 VA / 4.5 W
7.2 VA / 3.2 W (with completely charged Battery)
5 x LEDs
Lithium-Ion 3.6 V/2000 mAh with multiple protection circuit
II
IP 54 (designed for installation indoors)
maintained mode -5°C to +30°C
non maintained mode 0°C to +35°C
• Any foreign matter shall be re-
moved from the luminaire prior
to its initial operation!
• Observe the national safety
rules and regulations for pre-
vention of accidents as well
as the safety
instructions included in these
operating instructions marked
with !
3.Conformity with stan-
dards
The luminaire complies with EN
60 598-1, EN 60 598-2-22 and
DIN EN 1838.
Developed, manufactured and
tested according to DIN EN
ISO 9001.
