NOXON iRadio 300 / 360
Scenario 1 – the wired connection
If an Ethernet cable of a functioning network is plugged in at the time the device is
switched on, follow the steps below to set up the device quickly and easily:
SSID
Your WiFi network
WiFi network of your neigh...
[Rescan]
[Wired]
[Manual config]
rive in the right place. Normally, that's all there is to it, and the connection is made.
In rare cases, however, static IP addresses are assigned for certain access settings—
for more information, have a word with your network administrator. See "Sometimes
required: a fixed IP.
DHCP
DHCP enable
Set static IP
IP settings
IP adress
192 168
1
Subnet mask
255
255 255
Gateway adress
Gateway adress
192
168 1
52
If a DHCP server is active in your router – which is
the case in almost every current model – please
select [Wired].
The wizard now automatically connects to your
router and gets its network address from the DHCP
server. Every device in the network must have
such an identifier to ensure that the IP packets ar-
To assign a static IP to the NOXON, select [Manu-
al Config].
In the following menu, please select [Set static
IP].
Here you can enter the corresponding values us-
ing the navigation dial. To get to large numbers
(such as 192) more quickly, turn the dial to the left.
2
To go to the next field, press the dial or the OK
button on your remote control.
0
Then, you have to specify the gateway address.
1
