strip disappear into the nozzle housing.(fig.11)
4 With the nozzle positioned lengthwise and
the brush strip folded in, you can vacuum
clean small soft floor areas.Turn the tube 90
degrees anti-clockwise again until it is
positioned lengthwise with the brush strip
still folded in.(fig.12)
Crevice tool and small nozzle
1 Connect the crevice tool (1) or small nozzle
(2) directly to the handgrip or to the
tube.(fig.13)
Accessory holder
1 The accessory holder can simply be snapped
onto the handgrip.(fig.14)
The crevice tool and the small nozzle can be
stored in the accessory holder by pushing
them in the holder.(fig.15)
Please note the way in which the small nozzle
must be placed in the accessory holder.

Vacuum cleaning

Adjusting suction power
You can adjust the suction power while
vacuum cleaning
1 Adjust the suction power by means of the
electronic suction power control.(fig.16)
2 Set the knob to MAX for maximum suction
power.(fig.17)
Use maximum suction power for vacuum
cleaning very dirty carpets and hard floors.
3 Set the knob to MIN for minimal suction
power.
Use minimum power for vacuum cleaning
curtains, table carpets, etc.
Parking the tube
By inserting the ridge on the nozzle in the
parking slot, you can park the tube in a
convenient position.(fig.18)

Storing the vacuum cleaner

1 You can put the appliance in upright position
and attach the nozzle to the appliance by
inserting the ridge on the nozzle in the
slot.(fig.19)

Replacing the dustbag

1 Replace the dustbag as soon as the dustbag-
full indicator changes colour (even when the
nozzle is not placed on the floor).(fig.20)
2 Switch the appliance off.
3 Open the cover by pulling it upwards.(fig.21)
Place you fingers at the inlet of the cover and
press with your thumb on the ridge on top of the
cover.
4 Lift the dustbag holder out of the
appliance.(fig.22)
Make sure you hold the dustbag upright when
lifting it out of the appliance.
5 Remove the full dustbag from the holder by
pulling the cardboard tag.(fig.23)
When you do this, the dustbag will be
automatically sealed.
6 Slide the cardboard tag of the new dustbag
into the two grooves of the dustbag holder as
far as possible. Re-insert the dustbag holder
into the vacuum cleaner.(fig.24)
You cannot close the cover if no dustbag has
been inserted.
If provided, you can use the cotton dustbag
instead of paper dustbags.The cotton dustbag
can be used and emptied repeatedly.
To empty the cotton dustbag:
- Hold the dustbag over a dustbin.
- Remove the clip by sliding it off the dustbag
sideways.
- Undo the metal hooks.
- Close the dustbag by fastening the metal hooks
and sliding the clip back onto the bottom edge
of the dustbag.
Ordering dustbags
Philips s-bag™ paper dustbags are available under
type number FC8021 (4822480101113).
Philips s-bag™ clinic high filtration dustbags are
available under type number FC8022
(883802201010).
Philips cotton dustbags are available under
number FC8020 (432200493291).
7
