1. Microphone input : To be connected via an XLR plug.
The phantom power can be activated with switch 17. If you press this button all balanced microphone
inputs are powered by 48V which allows the use of condenser microphones.
2. Insert jack: Allows you to insert, for example, an equalizer in the mono channels.
3. LINE : Balanced Line
4. LINE Stereo: Balanced Line
inputs.
5. TAPE-IN: (stereo RCA) For the connection of Play-back devices such as CD players etc..
6. TAPE-OUT: To connect , for example, a tape deck for recording applications.
7. PHONES: To connect a headphone.
8. MAIN OUTPUTS: To connect to an amplifier (balanced
9. EFF SEND : To connect to the input of effect devices.
10. AUX SEND: To connect to a monitor-amplifier or active monitor speaker.
11. GAIN : To control the channel inputs gain, both for a microphone (XLR) and other signal sources (
12. PAN : To adjust the signal's position on the stereo basis.
13. HI-MID-LOW Equalizer : To adjust the frequencies of these 3-band EQ.
14. AUX: To adjust the channel volume sent to the AUX mix bus.
15. CHANNELFADER: To adjust the volume of the corresponding channel.
16. EFF: To adjust the effects volume for the corresponding channel.
17. Use this switch to activate the phantom power required for condenser microphones.
18. LEVEL DISPLAY: Reads the outputlevel . Make sure that the two clip-leds won't light up.
19. REPEAT: To adjust the frequency of Echo-Repeat. To much Repeat will cause a howl.
20. To adjust the Time-interval of Echo-Repeat. (Middle position is most effective).
21. PHONES control: To adjust the volume of the headphone.
22. AUX SEND control: To adjust the volume level of the AUX signal provided at connector 10.
23. EFF SEND control: To adjust the level of the signal that is sent to any external effect device via connector 9
(without the risk of distortion.)
24. MASTERFADER: To set the overall volume level.
SPECIFICATIONS:
INPUT CHANNELS 1~2
Mic input ........................................ electronically balanced
Freq. Response ........................................... 10Hz – 20kHz
Gain range ................................................ +14dB to +60dB
SNR ................................................................ 120dB E.I.N
Line input .................................................. electr. Balanced
Gain range ................................................... -6dB to +38dB
SNR ................................................................. 95dB E.I.N.
STEREO CHANNELS
Gain range ................. Line:-8 to +15dB / Mic: +13 to 60dB
SNR ..................................... Line: 96dB / Mic:104dB E.I.N
EQUALIZER
Low ............................................................... 50Hz - ±15dB
Mid ................................................................ 700Hz ±15dB
Hi .................................................................. 10kHz ±15dB
MAIN
Outputs ................................. +28dBu bal. / +22dBu unbal.
AUX SEND .................................................. +22dBu unbal.
EFF SEND ................................................... +22dBu unbal.
Tape out ...................................................+22DbU UNBAL.
Phones out ................................................... +15dBu / 150
¼" input.
¼" input
for stereo channels, which can be used in parallel to the microphone
¼" jacks)
.
¼").
