CONTROL FOR 1 FIRE ZONE AND 1 COMFORT ZONE
Power supply
Operating conditions
Protection degree
Colour
Dimensions WxHxD
Weight incl. batteries
Autonomy battery
Internal T-sensor
Max. load
Motor output
Fire switches & zones *
Comfort zones *
Smoke- and heat detectors
Priority switch
Wind- and rain sensor *
Connection of control units
Alarm output *
Fault output *
Supply output *
Line surveillance on
Visual indication (LED)
*
not present on Slave
Manufacturer:
AG.PLASTICS, Spinnerijstraat 100, B-8230 Harelbeke, Belgium, website: www.agplastics.com
SHE service: Tel.: +32 (0) 56 24 81 05 I e-mail: service@agp.be
Skycom CE Control:
Version
01 Nov. 2012
02 Nov. 2013
03 March 2015
04 Oct. 2016
Skycom CE Manual:
Version Release date
01 May 2013
02 Nov. 2013
03 March 2015
04 Oct. 2016
SKYCOM CE

TECHNICAL SPECIFICATIONS

: 230V AC / max. 1,7A
: - 5 °C to + 60 °C / Humidity max 90%, non- condensing/
internal use without aggressive vapers & gases
: IP54
: RAL 9003 (white)
: 286x238x113 mm
: 7,5 kg
: Min. 72 hours
: Alarm generated at 75°C
: 24V / 8A (Fuse F1: 8A Fast acting)
: 1 pc. (terminals 6mm2) – line detection: 1-4 lines
: 1 fire zone, 8 - 10 pcs. external fire switches,
depending on the load
: 1 comfort zone - unlimited number of switches
: 1 input - max. 20 pcs. detectors per control
: 1 input for an external Priority switch (Option PCB)
: Input for close all
: Bus connection integrates most functions -
Max. 35 controls in the same bus connection
: Potential free SPDT change over max. 48V 0,5A
: Potential free SPDT change over max. 48V 0,5A
: 24VDC 0,5A at 230VAC operation
: Motor lines, fire switches,smoke detector Priority switch,
and communication bus
: OK, AC fault, Low battery, Line fault, Alarm, comfort open
Date
First release
Software update (version 042) for option PCB for external priority close switch (Master &
Slave)
New PCB with low consumption, keypad, J9, J11, T-sensor, ...
SW update EMC (communication bus)
First release
Add external priority switch + general review
Add new Skymax CE, Cintramax CE, Skylux 160°CE with 2 motors
Add lip 7, new fireswitch, new main board
Skymax CE without positive safety: added
New wind and rain detector AWR-24/250 added
SHE survey added / EMC update PRIOR: ferrite + GND
Old schemes Cintramax and Skymax: removed
SHE-CONTROL

REVISIONS

Description
Description
AG.PLASTICS QUALITY
