b. Jumper J2 in pos. "Ext 3 wire" (Setting for Skymax
Unknown motor: line monitoring (1-3) with 3 wired motor connexion.
With jumper J3 (actuator output): you choose how many lines (number of 27KΩ)
you wish to detect - the same way as the motor line.
This setting demands 3 wire cable from motor output to motor.
c. Jumper J2/J3 is not mounted - No line monitoring for actuator output
J2
Actuator
Motor line monitor
Ext 3 wire monitor
(line 1)
4
J3
3
2
1
1
Electronic current limiter, type LIP function and setting (Skylux 160°CE, Cintramax CE, Skymax CE)
The current limiter type LIP (mounted on the opening system) is used as current limiter for the actuator. On the LIP5, and
younger version max. 3 times overload cut outs in the same direction is allowed. After which it will not be possible to run
in this direction again, before the motor has run in the opposite direction. Please note that when opening, the red LED in
the LIP must light. This indicates that polarity of the actuator is correct.
Table of LIP settings
Opening system
current limit
DIP 1
DIP 2
Type DIP 1 DIP 2 DIP 3
LIP5
Single
LIP6 *
Double
See diagram
LIP7
above
Single
Basic
LIP7
Single
Tandem
* SA Power LM Large - parallel operation: Jumper OPT mounted - both motors stop at the same time if one stops
because of overload.
** When DIP4 is OFF = Tandem Mode - both motors stop at the same time if no current flows in one (1,5 sec. reaction
time).
*** Required: an actuator with "reed" sensor (3-wire sensor black cable included).
SKYCOM CE
®
2 3
M1
Skylux 160° LM Skylux 160° LM
3A
ON
OFF
DIP 4 DIP 5
27K
ON
ON OFF ** = 27K ON
Tandem
27K
ON
27K ON = OFF = Slave
ON COM ON = Master
SHE-CONTROL
standard / Cintramax CE (old) / Skyvent
®
Skylux 160°: Mini + RM
Cintramax
4A
OFF
ON
DIP 6
not present
M1-M2 delay=OFF
not present
OFF = Synchro Mode
ON = Tandem Mode
AG.PLASTICS QUALITY
info@agp.be
www.agp.be
CE)
®
Actuator
J2
Motor line monitor
Ext 3 wire monitor
(line 1)
4 J3
3
2
1
1
Line 1
27K Ohm
(Only last
actuator)
Skymax
2,5A
ON
ON
DIP 7
not present
off: no delay
on: 7s delay
2 3
+ -
Actuator
24V Out
DIP 8
no function
